Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 172cm
MD
169cm - 179cm
LG
176cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
HIGH STRENGTH CARBON, TOOLING/DESIGN: 100% PROPRIETARY PANORAMA CYCLES, INTERNAL CABLE ROUTING FOR ADJUSTABLE SEATPOST, BRAKE STD: FLAT MOUNT, REAR RACK MOUNTS, WATER BOTTLE MOUNTS UNDER AND OVER THE DOWNTUBE, WATER BOTTLE MOUNTS ON SEAT TUBE, GAS TANK MOUNT ON TOP OF TOP TUBE, FENDER MOUNTS, 12MMX142MM REAR SPACING, BSA 68mm BOTTOM BRACKET, TAPERED 1-1/2¨ x 1-1/8¨ HEAD TUBE, INTEGRATED HEADSET: TOP IS42 LOWER IS52, DIA 31.8MM SEAT POST CLAMP, DIA 27.2MM SEAST POST, FRONT DERAILLEUR: BRAZE-ON REPLACEABLE, MAXIMUM TIRE CLEARANCE: 700X48MM OR 650X2.1¨, COMPATIBLE DI2, MAX CHAINRINGS: 2X 50/34T, 1X 46T, FRAME WEIGHT: 1350g (LARGE), COLOR: OLIVE GREEN KHAKI
Suspension Fork
HIGH STRENGTH CARBON, TOOLING/DESIGN: 100% PROPRIETARY PANORAMA CYCLES, TRIPLE CARGO CAGE MOUNTS, FENDER MOUNTS, 12MMX100MM SPACING, INTERNAL CABLE ROUTING FOR DYNAMO HUB, TAPERED STEER TUBE 1-1/8¨ / 1-1/2¨, MAX TIRE CLEARANCE : 700X50MM OR 650X2.1¨, COLOR: OLIVE GREEN KHAKI
Drivetrain
Rear Derailleur
SHIMANO RX822, GRX, SGS 12-SPEED
Front Derailleur
N/A
Shift Levers
SHIMANO GRX RX610 (left side shifter
Cassette
SHIMANO M7100-12, DEORE SLX, 10-51T, 12-SPEED
Crank
SHIMANO GRX RX610 38T 1X12, 170/172.5/175mm
Bottom Bracket
SHIMANO BBR60 ULTEGRA
Chain
SHIMANO M7100, DEORE SLX, 12 SPEED
Pedals
Not included
Wheels
Rims
HUNT 4SEASON GRAVEL DISC X WIDE 700c
Tires
TERAVAIL CANNONBALL 700X42 TAN, LIGHT AND SUPPLE
Brakes
Brakes
SHIMANO GRX RX610 (left side shifter
Cockpit
Stem
PROMAX DA-281, 31.8MM, 6DEG
Handlebar
RITCHEY COMP BUTANO V2, 46CM
Headset
FSA NO.42 IS
Seat
Saddle
WTB SILVERADO MEDIUM
Seatpost
KALLOY SP-3D2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.51 mm | 1.53 mm |
| Bottom Bracket Height | 274 mm | 274 mm | 274 mm |
| Front Center | 621 mm | 638 mm | 653 mm |
| Rake | 55 mm | 55 mm | 55 mm |
| Trail | 71 mm | 71 mm | 71 mm |
| Stack | 572 mm | 590 mm | 610 mm |
| Reach | 381 mm | 392 mm | 399 mm |
| Top Tube Length | 545 mm | 561 mm | 574 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 145 mm | 165 mm | 185 mm |
| Chainstay Length | 429 mm | 429 mm | 429 mm |
| Wheelbase | 1039 mm | 1056 mm | 1071 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm |
| Standover Height | 744 mm | 769 mm | 789 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 162 cm | 169 cm | 176 cm |
| Rider Max Height | 172 cm | 179 cm | 188 cm |
About this model
Katahdin GRX RX610 is part of the Panorama Katahdin model. Panorama released 12 bikes variations of this model so far. You can easily view all of the Panorama Katahdin bikes models from 2023, here.
Model range prices
Panorama Katahdin Rival 1x 2023 is the cheapest bike model and costs 1922$. Panorama Katahdin GRX RX822 2023 is the most expensive one and costs 3469$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Gravel bikes average price
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2023 and its price was 3180$. In conclusion, this bike price is 29.16% higher than the price of the average Gravel bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Katahdin GRX RX610 components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on Katahdin GRX RX610 are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Panorama Katahdin GRX RX610 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This bike is available in 3 sizes. They vary from 162 cm – 188 cm (5.31 ft – 6.17 ft). In short, you can easily find one that suits you.
