Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Rival, FSA -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 172cm
MD
169cm - 179cm
LG
176cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
HIGH STRENGTH CARBON, TOOLING/DESIGN: 100% PROPRIETARY PANORAMA CYCLES, INTERNAL CABLE ROUTING FOR ADJUSTABLE SEATPOST, BRAKE STD: FLAT MOUNT, REAR RACK MOUNTS, WATER BOTTLE MOUNTS UNDER AND OVER THE DOWNTUBE, WATER BOTTLE MOUNTS ON SEAT TUBER, GAS TANK MOUNT ON TOP OF TOP TUBE, FENDER MOUNTS, 12MMX142MM REAR SPACING, BSA 68mm BOTTOM BRACKET, TAPERED 1-1/2¨ x 1-1/8¨ HEAD TUBE, INTEGRATED HEADSET: TOP IS42 LOWER IS52, DIA 31.8MM SEAT POST CLAMP, DIA 27.2MM SEAST POST, FRONT DERAILLEUR: BRAZE-ON REPLACEABLE, MAXIMUM TIRE CLEARANCE: 700X48MM OR 650X2.1¨, COMPATIBLE DI2, MAX CHAINRINGS: 2X 50/34T, 1X 46T, FRAME WEIGHT: 1350g (LARGE), COLOR: BURGUNDY
Suspension Fork
HIGH STRENGTH CARBON, TOOLING/DESIGN: 100% PROPRIETARY PANORAMA CYCLES, TRIPLE CARGO CAGE MOUNTS, FENDER MOUNTS, 12MMX100MM SPACING, INTERNAL CABLE ROUTING FOR DYNAMO HUB, TAPERED STEER TUBE 1-1/8¨ / 1-1/2¨, MAX TIRE CLEARANCE : 700X50MM OR 650X2.1¨, COLOR: BURGUNDY
Drivetrain
Rear Derailleur
SRAM Rival
Front Derailleur
N/A
Shift Levers
SRAM RIVAL
Cassette
SUNRACE CSMX8 11-46T
Crank
FSA GOSSAMER COMPACT 1X, 38T
Bottom Bracket
FSA THREADED BSA 30MM
Chain
KMC X11
Pedals
Not included
Wheels
Rims
HUNTxPANORAMA ADVENTURE SPORT 650B
Tires
WTB VENTURE 650×47 ROAD PLUS TCS, TANWALL
Brakes
Brakes
YOKOZUNA MOTOKO ROAD
Brake Levers
SRAM RIVAL
Cockpit
Stem
PROMAX DA-281, 31.8MM, 6DEG
Handlebar
RITCHEY BEACON COMP, 46cm
Headset
FSA NO.42 IS
Seat
Saddle
PANORAMA SPEC. 140MMX265MM
Seatpost
KALLOY SP-3D2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.51 mm | 1.53 mm |
| Front Center | 621 mm | 638 mm | 653 mm |
| Rake | 55 mm | 55 mm | 55 mm |
| Trail | 71 mm | 71 mm | 71 mm |
| Stack | 572 mm | 590 mm | 610 mm |
| Reach | 381 mm | 392 mm | 399 mm |
| Top Tube Length | 545 mm | 561 mm | 574 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 145 mm | 165 mm | 185 mm |
| Chainstay Length | 429 mm | 429 mm | 429 mm |
| Wheelbase | 1039 mm | 1056 mm | 1071 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm |
| Standover Height | 744 mm | 769 mm | 789 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 162 cm | 169 cm | 176 cm |
| Rider Max Height | 172 cm | 179 cm | 188 cm |
About this model
Katahdin Rival 1x is part of the Panorama Katahdin model. Panorama released 10 bikes variations of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Panorama Katahdin Rival 1x 2022 is the cheapest bike model and costs 2747$. Panorama Katahdin GRX 2×11 2022 is the most expensive one and costs 3073$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2022 and its price was 2747$. Doing a quick comparison, we notice that Katahdin Rival 1x price is 11.58% more expensive than the average cost of a Gravel bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Katahdin Rival 1x components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When it comes to wheels, the Katahdin Rival 1x bike is equipped with the aluminum model. After 700c wheels, 650b is the second most popular choice for road bikes. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
Nothing is more important on a bike than its ability to brake properly. Panorama Katahdin Rival 1x is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Panorama Katahdin Rival 1x bike has 3 sizes, in the range of 162 cm – 188 cm (5.31 ft – 6.17 ft). In short, it won’t be difficult to find the right one for you.
