panorama Torngat 27.5 SUN RINGLE MULEFÜT 80SL V2, 27.5”, 32 HOLES 2023
2023 Mountain
Estimate price |
2,317$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 27.5" -
Groupset SLX, Race Face -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 169cm
MD
166cm - 179cm
LG
176cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
REYNOLDS 725 STEEL FRAME, INTERNAL CABLE ROUTING FOR DROPPER SEAT POST, SLIDING DROPOUTS – SINGLE SPEED / ROLHOFF-BELT DRIVE COMPATIBLE, POST MOUNT BRAKE STD, REAR RACK MOUNT, TRIPLE WATER BOTTLE MOUNT UNDER THE DOWNTUBE, WATER BOTTLE MOUNT ON SEAT TUBE AND TOP OF DOWNTUBE, GAS TANK MOUNT ON TOP OF TOP TUBE, ELECTRODEPOSITION SURFACE TREATMENT (CORROSION PROTECTION), 12MMX197MM REAR SPACING, 100mm BSA BOTTOM BRACKET, TAPERED 1-1/2¨ x 1-1/8¨ HEAD TUBE, DIA 34.9MM SEAT POST CLAMP, DIA 31.6MM SEAST POST, HEADSET: TOP ZS44 LOWER EC49, MAXIMUM TIRE CLEARANCE: 27.5¨X4.5¨; 26¨X5¨ ; 29¨X3¨
Suspension Fork
CUSTOM CARBON CONSTRUCTION, THREE PACK MOUNTS ON EACH SIDE, 15MMX150MM AXLE, TAPERED STEER TUBE 1-1/8¨ / 1-1/2¨, MAXIMUM TIRE CLEARANCE: 27.5¨X4.5¨; 26¨X5¨ ; 29¨X3¨
Drivetrain
Rear Derailleur
SHIMANO SLX RD-M7100, 12 SPEEDS
Shift Levers
SHIMANO SLX SL-M7100, 12 SPEEDS
Cassette
SHIMANO SLX CS-M7100-12, 10-51T, 12 SPEEDS
Crank
RACE FACE AEFFECT, 28T STEEL CINCH DM CHAINRING
Bottom Bracket
RACE FACE BSA TEAM
Chain
SHIMANO DEORE CN-M6100, 12 SPEEDS
Pedals
Not included
Wheels
Front Hub
SUN RINGLE SRC – MICROSPLINE FREEHUB BODY
Rear Hub
SUN RINGLE SRC – MICROSPLINE FREEHUB BODY
Spokes
14G STAINLESS BLACK
Tires
VEE SNOW AVALANCHE 27.5X4.5?, 120TPI, TUBELESS READY, STUDDABLE
Brakes
Brakes
SRAM LEVEL HYDRAULIC
Cockpit
Stem
RITCHEY MTB TRAIL, 45MM X 3DEG
Handlebar
RITCHEY MTN COMP, 800MM, 20MM RISE, 10DEG SWEEP
Headset
FSA NO.9M/NO.12B
Seat
Saddle
WTB PURE
Seatpost
KALLOY SP-719
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.44 mm | 1.39 mm |
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm |
| Front Center | 689 mm | 718 mm | 742 mm |
| Rake | 40 mm | 40 mm | 40 mm |
| Trail | 91 mm | 90 mm | 91 mm |
| Stack | 606 mm | 620 mm | 629 mm |
| Reach | 408 mm | 431 mm | 453 mm |
| Top Tube Length | 583 mm | 610 mm | 634 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 380 mm | 425 mm | 480 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 105 mm | 120 mm | 130 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1129 mm | 1158 mm | 1183 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Standover Height | 699 mm | 742 mm | 808 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 154 cm | 166 cm | 176 cm |
| Rider Max Height | 169 cm | 179 cm | 195 cm |
About this model
Torngat 27.5 SUN RINGLE MULEFÜT 80SL V2, 27.5”, 32 HOLES completes the Panorama Torngat model. There are 5 bikes that carry this model name. Take a sneak peek at all Panorama Torngat bikes models from 2023, by clicking here.
Model range prices
The most economical model, the Panorama Torngat 27.5 SUN RINGLE MULEFÜT 80SL V2, 27.5”, 32 HOLES 2023 has a starting price of 2313$. Panorama Torngat Ti SLX/XT 2023 on the other hand is the most expensive at 4143$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Fatbike bikes
According to our math, the average price for a trustworthy Fatbike bike is 1743$. However, even if your budget is less than the average, you might still be able to get a top-quality Fatbike bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Panorama released this model in 2023, its price was 2313$. In conclusion, this bike price is 32.7% higher than the price of the average Fatbike bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Torngat 27.5 SUN RINGLE MULEFÜT 80SL V2, 27.5”, 32 HOLES components
Fork material
Torngat 27.5 SUN RINGLE MULEFÜT 80SL V2, 27.5”, 32 HOLES has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The wheels on Torngat 27.5 SUN RINGLE MULEFÜT 80SL V2, 27.5”, 32 HOLES are the 27.5″ type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Panorama Torngat 27.5 SUN RINGLE MULEFÜT 80SL V2, 27.5”, 32 HOLES has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Panorama Torngat 27.5 SUN RINGLE MULEFÜT 80SL V2, 27.5”, 32 HOLES bike has 3 sizes, in the range of 154 cm – 195 cm (5.05 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
