Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain Electronic -
Brakes Rim
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
163cm - 174cm
MD
170cm - 181cm
MD/LG
175cm - 187cm
LG
181cm - 193cm
XL
188cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Drivetrain
Rear Derailleur
Shimano Ultegra Di2 RD
Front Derailleur
Braze-on mount, replaceable
Shift Levers
Shimano Ultegra Di2 Shifters
Cassette
Shimano Ultegra Cassette
Crank
Shimano Ultegra Crankset
Bottom Bracket
Press Fit 30 (68mm x 46mm)
Chain
Shimano Ultegra Chain
Wheels
Rims
DT 1800 Series Wheels
Tires
Vittoria Corsa Tires
Brakes
Brakes
Caliper, centermount, internally routed
Cockpit
Stem
Parlee Carbon Stem
Handlebar
Parlee Carbon Handlebar
Headset
Integrated Cane Creek, IS41 upper, IS47 lower
Seat
Seatpost
31.6mm, hidden binder
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.483 mm | 1.53 mm | 1.537 mm | 1.565 mm | 1.566 mm | 1.589 mm |
| Bottom Bracket Height | 329 mm | 329 mm | 329 mm | 329 mm | 329 mm | 329 mm |
| Front Center | 56 mm | 57 mm | 58 mm | 58 mm | 60 mm | 60 mm |
| Rake | 4.3 mm | 4.3 mm | 4.3 mm | 4.3 mm | 4.3 mm | 4.3 mm |
| Trail | 593 mm | 587 mm | 593 mm | 594 mm | 607 mm | 622 mm |
| Stack | 534 mm | 557 mm | 575 mm | 593 mm | 609 mm | 631 mm |
| Reach | 360 mm | 364 mm | 374 mm | 379 mm | 389 mm | 397 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 434 mm | 455 mm | 472 mm | 492 mm | 506 mm | 520 mm |
| Head Tube Angle | 71.5 ° | 72.5 ° | 73 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Wheelbase | 96 mm | 97 mm | 98 mm | 98 mm | 100 mm | 100 mm |
| Bottom Bracket Drop | 7 mm | 7 mm | 7 mm | 7 mm | 7 mm | 7 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 163 cm | 170 cm | 175 cm | 181 cm | 188 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 200 cm |
About this model
Altum LE – Ultegra/Di2 completes the Parlee Altum model. Parlee released 13 bikes variations of this model so far. Take a sneak peek at all Parlee Altum bikes models from 2020, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Race bikes average price
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Altum LE – Ultegra/Di2 components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When it comes to wheels, the Altum LE – Ultegra/Di2 bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Altum LE – Ultegra/Di2 comes with Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
Sizes
There are 6 sizes available for this model. Rider height can be anywhere between 155 cm – 200 cm (5.09 ft – 6.56 ft). In conclusion, finding one for you shouldn’t be a problem.
