Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 130mm -
Fork Fox Performance Elite Float 34
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX 34 Performance Elite
Rear Shock
FOX DPX2 Performance Elite, 3-position lever, 7.875" x 2.25"
Drivetrain
Rear Derailleur
Shimano XT M8100, 12-speed
Front Derailleur
None
Shift Levers
Shimano XT M8100, 12-speed
Cassette
Shimano SLX M7100, 10-51 tooth, 12-speed
Crank
Shimano XT M8100
Bottom Bracket
BSA, 73mm, threaded
Chain Guide
None
Pedals
None
Wheels
Front Hub
Shimano
Rear Hub
Shimano
Rims
SUNringlé Düroc 30
Tires
Front: Maxxis DHF 29" x 2.5" WT, EXO, TR, Rear: Maxxis DHR II 29" x 2.4" WT, EXO, TR
Brakes
Brakes
Magura MT Thirty, 4-piston, 203mm rotors
Brake Levers
Magura MT Thirty
Seat
Seatpost
SDG Tellis, Travel: 125mm on S/M, 150mm on L/XL
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.48 mm | 1.43 mm | 1.39 mm |
| Bottom Bracket Height | 336 mm | 336 mm | 336 mm | 336 mm |
| Stack | 627 mm | 632 mm | 642 mm | 651 mm |
| Reach | 402 mm | 426 mm | 448 mm | 470 mm |
| Top Tube Length | 575 mm | 600 mm | 625 mm | 649 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 405 mm | 432 mm | 462 mm | 505 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 105 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1145 mm | 1171 mm | 1197 mm | 1222 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 38 mm | 38 mm |
| Standover Height | 715 mm | 715 mm | 724 mm | 722 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
591 S completes the Patrol 591 model. There are 2 bikes that carry this model name. Check out the entire range from 2020 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
591 S components
Fork
The 591 S comes factory-installed with the Fox Performance Elite Float 34 fork. This has a travel range of 140mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
As for the rear shock, this bike has the FOX DPX2 Performance Elite model, with a travel of 130mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
As for the wheels, Patrol 591 S 2020, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The 591 S has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Patrol 591 S includes a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
