Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 12" -
Travel Front 160mm -
Travel Rear 150mm -
Fork RockShox 35 Silver
-
Groupset SX Eagle, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
PATROL 691 SL, 12×157 Superboost, 150MM
Suspension Fork
Rockshox 35 Silver, 160 mm travel. 44mm offset
Rear Shock
X Fusion 02 Pro RLR, 8.5×2.5
Drivetrain
Rear Derailleur
SRAM SX EAGLE 12s
Shift Levers
SRAM SX EAGLE 12s
Crank
Truvatif Descendant, Alumunium, Eagle, Superboost, DUB, 32T
Wheels
Rims
Patrol Rims 35mm with Shimano SLX Superboost Hub
Tires
MAXXIS
Brakes
Brakes
Shimano MT420
Cockpit
Stem
PATROL ENDURO
Handlebar
PATROL ENDURO
Grips
SDG
Seat
Saddle
SDG
Seatpost
KSP900-I, 30.9mm, 150mm (S/M) – 170mm (L/XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.34 mm | 1.28 mm | 1.25 mm |
| Bottom Bracket Height | 356 mm | 356 mm | 356 mm | 356 mm |
| Front Center | 742 mm | 768 mm | 788 mm | 816 mm |
| Rake | 34 mm | 34 mm | 34 mm | 35 mm |
| Stack | 599 mm | 604 mm | 604 mm | 617 mm |
| Reach | 427 mm | 451 mm | 471 mm | 492 mm |
| Top Tube Length | 571 mm | 597 mm | 617 mm | 644 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 405 mm | 432 mm | 455 mm | 470 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 105 mm | 110 mm | 110 mm | 125 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1192 mm | 1218 mm | 1238 mm | 1266 mm |
| Bottom Bracket Drop | -12 mm | -12 mm | -12 mm | -12 mm |
| Standover Height | 735 mm | 737 mm | 740 mm | 740 mm |
| Wheels | 12" | 12" | 12" | 12" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
691 sl belongs to the Patrol 691 model. Patrol released 5 bikes variations of this model so far. You can easily view all of the Patrol 691 bikes models from 2021, here.
Model range prices
Patrol 691 sl 2021 is the most economical model, with a starting price of 2999$. Patrol 691 Evo 2021 on the other hand costs 4699$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Enduro bikes
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, this doesn’t mean that if you spend less money on an Enduro bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2021 for 2999$. Comparing the average cost of an Enduro bike to this one, you will see that 691 sl price is 20.01% lower.
Overview of components
Fork
The RockShox 35 Silver is included from the factory. It has a travel distance of 160mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this bike is X Fusion 02 Pro RLR, with a travel distance of 150mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The wheels on 691 sl are the 12″ aluminum type. The 12″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
For your safety, it is important to have quality breaks on your bike. Patrol 691 sl has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
