Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Travel Front 40mm -
Fork Fox Performance Float 32
-
Groupset GRX 800 -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
PATROL carbon gravel, 12×142 mm
Suspension Fork
FOX Performance, 32 Taper Cast 40mm travel
Drivetrain
Rear Derailleur
SHIMANO GRX RX812, 11s
Shift Levers
SHIMANO GRX RX810
Cassette
SHIMANO SLX M7000, 11s, 11-42t
Crank
SHIMANO GRX FC-RX810-1, 42t
Wheels
Rims
EASTON EA70 AX
Tires
PIRELLI Cinturato™ Gravel H, 700×40c
Brakes
Brakes
Hydraulic Disc
Cockpit
Handlebar
EASTON EA70, 420mm
Seat
Seatpost
FOX Transfer SL Performance, 27.2mm, 50mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm |
|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.49 mm | 1.49 mm |
| Bottom Bracket Height | 276 mm | 276 mm | 276 mm |
| Front Center | 605 mm | 609 mm | 615 mm |
| Rake | -4 mm | -8 mm | -7 mm |
| Trail | 137 mm | 141 mm | 136 mm |
| Stack | 559 mm | 561 mm | 572 mm |
| Reach | 368 mm | 376 mm | 383 mm |
| Top Tube Length | 532 mm | 541 mm | 554 mm |
| Seat Tube Angle | 73.75 ° | 73.75 ° | 73.5 ° |
| Seat Tube Length | 410 mm | 430 mm | 470 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° |
| Head Tube Length | 95 mm | 95 mm | 105 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm |
| Wheelbase | 1010 mm | 1014 mm | 1020 mm |
| Bottom Bracket Drop | -80 mm | -80 mm | -80 mm |
| Standover Height | 683 mm | 699 mm | 735 mm |
| Wheels | 700 | 700 | 700 |
About this model
cg700 belongs to the Patrol Cg700 model. There are 2 bikes that carry this model name. You can easily view all of the Patrol Cg700 bikes models from 2022, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
cg700 components
Fork
Patrol cg700 2022 bike is equipped with the Fox Performance Float 32 fork, and has 40mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The cg700 2022 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Patrol cg700 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Dropper post
Patrol cg700 includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
