Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 160mm -
Travel Rear 150mm -
Fork Fox Factory Float 38
-
Groupset XT, Shimano -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery SMP, 640Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
PATROL alloy electric all-mountain, 12×148 mm, 150mm travel
Suspension Fork
FOX 38 E Factory, 160mm travel
Rear Shock
FOX Float DPX2, 3-pos, Kashima
Drivetrain
Rear Derailleur
SHIMANO Deore XT M8100, 12s
Shift Levers
SHIMANO Deore XT M8100-R
Cassette
SHIMANO SLX M7100, 12s, 12-51t
Crank
SHIMANO FC-M8150, SM-CRE80-12-B, 34t
Wheels
Rims
SUNringlé Düroc SD37 rims with SHIMANO hubs
Tires
MAXXIS Minion DHF EXO/TR (F), DHR II foldable (R), 29×2.60
Brakes
Brakes
MAGURA MT5N, 4-piston F/R
Seat
Seatpost
FOX Transfer Factory, 31.6mm, 125mm
Motor & Battery
Motor
SHIMANO Steps EP8
Battery
SMP, 640Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.349 mm | 1.293 mm | 1.28 mm |
| Bottom Bracket Height | 349 mm | 349 mm | 349 mm | 349 mm |
| Front Center | 755 mm | 777 mm | 800 mm | 819 mm |
| Rake | 21 mm | 21 mm | 23 mm | 22 mm |
| Trail | 151 mm | 151 mm | 149 mm | 150 mm |
| Stack | 609 mm | 614 mm | 614 mm | 627 mm |
| Reach | 435 mm | 455 mm | 475 mm | 490 mm |
| Top Tube Length | 566 mm | 587 mm | 609 mm | 627 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 400 mm | 420 mm | 455 mm | 470 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 105 mm | 110 mm | 115 mm | 125 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1199 mm | 1221 mm | 1244 mm | 1263 mm |
| Bottom Bracket Drop | -27 mm | -27 mm | -27 mm | -27 mm |
| Standover Height | 716 mm | 719 mm | 722 mm | 724 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
e-six s is part of the Patrol E E Six model. Patrol launched 6 e-bikes of this model so far. Take a sneak peek at all Patrol E E Six e-bikes models from 2022, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Enduro e-bikes
According to our calculations, the average cost of an Enduro e-bike that is reliable is 4785$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Overview of components
Fork
The e-six s comes factory-installed with the Fox Factory Float 38 fork. This has a travel range of 160mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
As for the rear shock, this e-bike has the FOX Float DPX2 model, with a travel of 150mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
When it comes to wheels, the e-six s e-bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
Patrol e-six s includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
