Pinarello DOGMA F SUPER RECORD EPS Rim 2022
2022 Road
Weight | 6.9 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Super Record EPS, Campagnolo -
Suspension Rigid -
Drivetrain Electronic -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
torayca t1100 1k dream carbon with nanoalloy technology, ticr™ cable routing, italian bb, uci approved
Suspension Fork
f12 onda fork with forkflap™, 1.5' upper and lower steerer, ultra light headset bearings
Drivetrain
Rear Derailleur
campagnolo super record eps 12s
Front Derailleur
campagnolo stiffness increaser eps 12s
Cassette
campagnolo super record eps 12s
Bottom Bracket
campagnolo super record
Chain
campagnolo record 12s
Wheels
Rims
bora ultra wto
Tires
pirelli pzero race 26mm, black 127 tpi aramid breaker. max tyre size 28mm (width as measured)
Brakes
Brakes
campagolo super record direct mount caliper
Cockpit
Handlebar
most ultragrip evo 3mm black
Seat
Saddle
most linx ultrafast superflow l carbon large 145mm
Seatpost
Pinarello Aero Seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 42cm* | 44cm | 46.5cm | 47cm | 50cm | 51.5cm | 53cm | 54cm | 55cm | 56cm | 57.5cm | 59.5cm | 62cm* |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.43 mm | 1.42 mm | 1.43 mm | 1.41 mm | 1.41 mm | 1.42 mm | 1.43 mm | 1.45 mm | 1.46 mm | 1.48 mm | 1.56 mm | 1.59 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 264 mm | 264 mm | 264 mm | 264 mm | 264 mm | 264 mm | 264 mm | 264 mm | 264 mm | 269 mm | 269 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Stack | 496.3 mm | 504 mm | 515.6 mm | 528.2 mm | 523.4 mm | 530.3 mm | 540.6 mm | 549.2 mm | 559.6 mm | 568.2 mm | 582.8 mm | 611.3 mm | 649.7 mm |
| Reach | 346.9 mm | 352.3 mm | 362.8 mm | 368.5 mm | 370.1 mm | 376 mm | 381.3 mm | 383 mm | 386.8 mm | 388.7 mm | 394.7 mm | 391.3 mm | 408.1 mm |
| Top Tube Length | 496 mm | 501 mm | 513 mm | 523 mm | 523 mm | 533 mm | 543 mm | 548 mm | 555 mm | 563 mm | 573 mm | 585 mm | 618 mm |
| Seat Tube Angle | 74.4 ° | 74.4 ° | 74.4 ° | 74 ° | 74 ° | 73.7 ° | 73.7 ° | 73.4 ° | 73.4 ° | 73 ° | 73 ° | 72.4 ° | 72 ° |
| Seat Tube Length | 415 mm | 435 mm | 455 mm | 455 mm | 480 mm | 495 mm | 510 mm | 520 mm | 530 mm | 540 mm | 555 mm | 575 mm | 615 mm |
| Head Tube Angle | 69.15 ° | 70 ° | 70.5 ° | 71.4 ° | 71.4 ° | 72 ° | 72.5 ° | 72.8 ° | 72.8 ° | 73.2 ° | 73.7 ° | 73.4 ° | 73.4 ° |
| Head Tube Length | 94 mm | 99 mm | 104 mm | 114 mm | 109 mm | 114 mm | 123 mm | 131 mm | 142 mm | 149.5 mm | 163 mm | 199 mm | 239 mm |
| Chainstay Length | 404 mm | 404 mm | 404 mm | 404 mm | 404 mm | 404 mm | 404 mm | 404 mm | 406 mm | 406 mm | 406 mm | 406 mm | 409 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 67 mm | 67 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
DOGMA F SUPER RECORD EPS Rim completes the Pinarello Dogma model. 171 bikes variations carry this model name so far. You can easily view all of the Pinarello Dogma bikes models from 2022, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Race bikes
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, you could also get a good Race bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Race bikes average weight
Race bikes weigh an average of 6.82 kg (15.04 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Weighing 6.9 kg (15.21 lbs), the DOGMA F SUPER RECORD EPS Rim model is slightly heavier than average. To sum up, it’s 1.17% heavier than the average weight of Race bikes.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When it comes to wheels, the DOGMA F SUPER RECORD EPS Rim bike is equipped with the 700c carbon model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Pinarello DOGMA F SUPER RECORD EPS Rim is equipped with Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
