Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Monocoque Carbon
Suspension Fork
Pinarello GAN Carbon
Drivetrain
Rear Derailleur
Shimano 105 R7000
Front Derailleur
Shimano 105 R7000
Shift Levers
Shimano 105 R7000
Cassette
Shimano 105 R7000, 11-28
Crank
Shimano RS-510, 52/36
Bottom Bracket
Shimano
Chain
Shimano HG601
Pedals
Not Included
Wheels
Rims
Fulcrum Racing 600
Tires
Vittoria Zaffiro 25c
Brakes
Brakes
MOst B-Max
Disk Rotors
Shimano
Cockpit
Stem
MOst 4bolt
Handlebar
MOst Xylon
Headset
Drop-In 1 1/8" - 1 1/2"
Seat
Saddle
MOST LYNX
Seatpost
Aero Full Carbon UD
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 44cm | 46.5cm | 50cm | 51.5cm | 53cm | 54cm | 55cm | 56cm | 57.5cm | 59.5cm |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.39 mm | 1.4 mm | 1.4 mm | 1.4 mm | 1.44 mm | 1.46 mm | 1.47 mm | 1.49 mm | 1.53 mm |
| Stack | 512 mm | 519 mm | 531 mm | 538 mm | 549 mm | 562 mm | 573 mm | 581 mm | 596 mm | 615 mm |
| Reach | 360 mm | 373 mm | 378 mm | 384 mm | 392 mm | 390 mm | 393 mm | 396 mm | 401 mm | 401 mm |
| Top Tube Length | 509 mm | 521 mm | 531 mm | 541 mm | 551 mm | 556 mm | 563 mm | 571 mm | 581 mm | 593 mm |
| Seat Tube Angle | 74.4 ° | 74.4 ° | 74 ° | 73.7 ° | 73.7 ° | 73.4 ° | 73.4 ° | 73 ° | 73 ° | 72.4 ° |
| Seat Tube Length | 440 mm | 465 mm | 500 mm | 515 mm | 530 mm | 540 mm | 550 mm | 560 mm | 575 mm | 595 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71.4 ° | 72 ° | 72.5 ° | 72.8 ° | 72.8 ° | 73.2 ° | 73.7 ° | 73.4 ° |
| Head Tube Length | 115 mm | 120 mm | 125 mm | 130 mm | 139 mm | 152 mm | 163 mm | 170 mm | 184 mm | 210 mm |
| Chainstay Length | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm | 414 mm | 416 mm | 416 mm | 416 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
GAN 105 Bike completes the Pinarello Gan model. There are 43 bikes that carry this model name. Take a sneak peek at all Pinarello Gan bikes models from 2020, by clicking here.
Model range prices
Pinarello GAN 105 Bike 2020 is the cheapest bike model and costs 2250$. Pinarello GAN GR 105 Bike 2020 is the most expensive one and costs 3350$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Race bikes average price
Our math shows that the average cost of a dependable Race bike is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2250$. Comparing the average cost of a Race bike to this one, you will see that GAN 105 Bike price is 48.89% lower.
GAN 105 Bike components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When it comes to wheels, the GAN 105 Bike bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The GAN 105 Bike comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
