Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GRX 600 -
Suspension Rigid -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
TorayCa T600 UD, Internal Cable Routing, Italian BB
Suspension Fork
grevil onda fork with forkflap™, tapered head tube
Drivetrain
Rear Derailleur
Shimano GRX 600 2X
Cassette
Shimano GRX
Crank
Shimano GRX 600 2X
Bottom Bracket
Shimano GRX
Chain
Shimano GRX
Brakes
Brakes
Front: Shimano GRX, 2 pistons caliper, 160mm rotor, Rear: Shimano GRX, 2 pistons caliper, 160mm rotor
Cockpit
Stem
Tiger Aero Alu TiCR
Handlebar
Jaguar XA Aero TiCR
Seat
Saddle
Most Lynx Aircross FEC Alloy Large 145mm
Seatpost
most alu round seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52.2cm | 53.5cm | 55cm | 56.5cm | 58.2cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.5 mm | 1.51 mm | 1.52 mm | 1.54 mm | 1.55 mm |
| Bottom Bracket Height | 277 mm | 277 mm | 277 mm | 277 mm | 277 mm | 277 mm |
| Rake | 50 mm | 50 mm | 50 mm | 47 mm | 47 mm | 47 mm |
| Stack | 545.4 mm | 557.7 mm | 575.6 mm | 592.8 mm | 609 mm | 626.1 mm |
| Reach | 365 mm | 371.9 mm | 380.4 mm | 388.9 mm | 396.5 mm | 404.2 mm |
| Top Tube Length | 524 mm | 537 mm | 552 mm | 567 mm | 584 mm | 602 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.75 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 550 mm | 575 mm | 600 mm |
| Head Tube Angle | 69.75 ° | 70 ° | 70.25 ° | 71 ° | 71.25 ° | 71.5 ° |
| Head Tube Length | 125 mm | 137 mm | 155 mm | 169 mm | 185 mm | 202 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Granger X1 Disc belongs to the Pinarello Granger model. There are 6 bikes that carry this model name. You can easily view all of the Pinarello Granger bikes models from 2023, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The wheels on Granger X1 Disc are the 700c type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Pinarello Granger X1 Disc is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
