Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force eTap -
Suspension Rigid -
Motor Fazua 250W 60Nm mid-drive -
Battery Fazua® Evation 1.0 250Wh -
Drivetrain Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
torayca t700 ud, with integrated battery and cable routing, 12x142 tru-axle
Suspension Fork
Nytro Gravel Onda Carbon Fork with ForkFlap™, Tapered head tube
Drivetrain
Rear Derailleur
SRAM force etap axs
Front Derailleur
SRAM force etap axs
Cassette
SRAM force xg-1270, 12s
Bottom Bracket
Fazua Bottom Bracked
Chain
SRAM force 12s
Wheels
Rims
Fulcrum Racing 500
Tires
maxxis rambler 700x40c
Brakes
Brakes
SRAM Force 2 pistons caliper, 160mm rotor
Cockpit
Stem
Tiger Alu Aero Di2
Handlebar
Jaguar XA Aero Di2
Seat
Saddle
Most Lynx Aircross FEC Alloy Large 145mm
Seatpost
Pinarello Aero Seatpost
Motor & Battery
Motor
Fazua® Evation Ride 50
Battery
Fazua® Evation 1.0 250Wh
Remote
fazua® remote fx
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 53cm | 56cm | 59cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.51 mm | 1.5 mm | 1.54 mm | 1.58 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Stack | 543 mm | 545 mm | 556 mm | 582 mm | 607.5 mm |
| Reach | 361 mm | 362 mm | 370 mm | 377.5 mm | 384 mm |
| Top Tube Length | 530 mm | 534 mm | 549 mm | 569 mm | 589 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 72.5 ° | 72 ° | 71.5 ° |
| Seat Tube Length | 462 mm | 492 mm | 522 mm | 552 mm | 582 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 135 mm | 135 mm | 145 mm | 170 mm | 195 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Nytro Gravel Force belongs to the Pinarello E Nytro model. There are 26 e-bikes that carry this model name. Check out the entire range from 2022 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Race e-bikes average price
If you want to purchase a solid Race e-bike, it is important to know that the average cost is 4156$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Nytro Gravel Force components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on Nytro Gravel Force are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Pinarello Nytro Gravel Force has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
