Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Torayca T600 UD, internal cable routing, Italian BB, UCI approved
Suspension Fork
Razha Onda Fork with ForkFlap™, tapered head tube
Drivetrain
Rear Derailleur
shimano tiagra 4700 gs 10s
Front Derailleur
shimano tiagra 4700 10s
Cassette
Shimano HG500 10s
Bottom Bracket
shimano tiagra
Chain
shimano tiagra 4700 10s
Wheels
Rims
Shimano RS
Tires
Pirelli P7 - Black, 60tpi Nylon breaker, max tyre size 28mm (width as measured)
Brakes
Brakes
shimano tiagra 4700, 2 pistons caliper, 160mm rotor
Cockpit
Stem
most alu
Handlebar
most alu
Seat
Saddle
most saddle
Seatpost
most alu round seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 48.5cm | 52cm | 53.5cm | 55cm | 56cm | 57cm | 58cm | 59.5cm | 61.5cm |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.39 mm | 1.4 mm | 1.4 mm | 1.42 mm | 1.44 mm | 1.45 mm | 1.46 mm | 1.48 mm | 1.53 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 264 mm | 264 mm | 264 mm | 264 mm | 264 mm | 264 mm | 264 mm | 269 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Stack | 511 mm | 518 mm | 531 mm | 537 mm | 552 mm | 561 mm | 572 mm | 580 mm | 595 mm | 614 mm |
| Reach | 361 mm | 373 mm | 378 mm | 384 mm | 390 mm | 390 mm | 394 mm | 396 mm | 402 mm | 401 mm |
| Top Tube Length | 509 mm | 521 mm | 531 mm | 541 mm | 551 mm | 556 mm | 563 mm | 571 mm | 581 mm | 593 mm |
| Seat Tube Angle | 74.4 ° | 74.4 ° | 74 ° | 73.7 ° | 73.7 ° | 73.4 ° | 73.4 ° | 73 ° | 73 ° | 72.4 ° |
| Seat Tube Length | 440 mm | 465 mm | 500 mm | 515 mm | 530 mm | 540 mm | 550 mm | 560 mm | 575 mm | 595 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71.4 ° | 72 ° | 72.5 ° | 72.8 ° | 72.8 ° | 73.2 ° | 73.7 ° | 73.4 ° |
| Head Tube Length | 115 mm | 120 mm | 125 mm | 130 mm | 144 mm | 152 mm | 163 mm | 170 mm | 184 mm | 210 mm |
| Chainstay Length | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm | 418 mm | 418 mm | 418 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 67 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Razha Tiagra Disc is part of the Pinarello Razha model. 10 bikes variations carry this model name so far. You can easily view all of the Pinarello Razha bikes models from 2022, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Endurance bikes
Our math shows that the average cost of a dependable Endurance bike is 2346$. However, even though the average price of an Endurance bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
When leaving the production line, the Razha Tiagra Disc model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Razha Tiagra Disc comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
