Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6013-T6 heat treated alloy, w/Triple butted top tube, down tube & smooth welds. 3 x bottle cage mounts, Internal cable routing for mechanical and Di2, interchangeable dropout & rack/mudguard mounts.
Suspension Fork
Full carbon fork and Alloy steerer w/flat mount and mudguard mounts
Drivetrain
Rear Derailleur
Shimano Tiagra 4700 GS 10 speed
Front Derailleur
Shimano Tiagra 4700 31.8mm band on
Shift Levers
Shimano Tiagra 4700 10 speed
Cassette
Shimano HG500 10 speed 11-32T
Bottom Bracket
Shimano RS500 BSA thread
Chain
KMC X10
Pedals
Not Supplied
Wheels
Front Hub
Loose ball bearing 32H 12 x 100mm
Rear Hub
Novatec 32H 2 sealed bearing 12 x 142mm
Rims
WTB ST i19 TCS 700c 32 hole, pinned, tubeless ready
Tires
Donnelly Strada LGG 700 x 28c
Brakes
Brakes
TRP Spyre mechanical discs w/160mm Rotors
Cockpit
Stem
Pinnacle alloy road, +/- 7 degree, S - 90mm, M - 100mm, L - 110mm, XL - 120mm
Handlebar
Pinnacle 6061 alloy road bar,118mm drop, 70mm reach, S/M - 420mm, L/XL - 440mm
Headset
FSA Orbit C-40-ACB, No.42
Seat
Saddle
Pinnacle men's road
Seatpost
Pinnacle aluminium 350mm x 27.2mm
Model Overview
Arkose R1 completes the Pinnacle Arkose model. There are 15 bikes that carry this model name. Check out the entire range from 2019 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Gravel bikes average weight
On a deeper look, we notice that the average weight of a Gravel bike is 8.13 kg (17.92 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
With a weight of 10.26 kg (22.62 lbs), Pinnacle bike is much heavier than average. In other words, this model is 26.2% heavier than the average Gravel bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork material
The fork is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
As for the wheels, Pinnacle Arkose R1 2019, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Pinnacle Arkose R1 is equipped with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
This bike has one size only, so it might not fit you. In conclusion, make sure it fits you, or look for another model.
