Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Wheels 27.5" -
Suspension Rigid
Sizing
Recommended size guide.
SM
162cm - 174cm
MD
171cm - 182cm
LG
179cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
LES Fat
Suspension Fork
Pivot LES Fat Carbon Disc
Rear Shock
None
Cockpit
Headset
Pivot Precision Sealed Cartridge
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.48 mm | 1.46 mm |
| Bottom Bracket Height | 311 mm | 311 mm | 311 mm |
| Stack | 602 mm | 616 mm | 631 mm |
| Reach | 394 mm | 415 mm | 432 mm |
| Top Tube Length | 580 mm | 605 mm | 627 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 102 mm | 117 mm | 133 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1094 mm | 1120 mm | 1143 mm |
| Bottom Bracket Drop | 44 mm | 44 mm | 44 mm |
| Standover Height | 684 mm | 716 mm | 753 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 162 cm | 171 cm | 179 cm |
| Rider Max Height | 174 cm | 182 cm | 188 cm |
About this model
LES Fat Frame belongs to the Pivot Les model. Pivot released 126 frames variations of this model so far. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
The most economical model, the Pivot LES 27.5 Team Frame 2019 has a starting price of 2099$. Pivot LES Frame Kit 2019 on the other hand is the most expensive at 3099$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Fatbike frames average price
Our math shows that the average cost of a dependable Fatbike frame is 1277$. However, you could also get a good Fatbike frame even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your frame, always do some components analysis and read reviews.
At the moment of the release date, Pivot LES Fat Frame price was 2499$. If we compare this with the average Fatbike frame cost we notice that the price is 95.69% more expensive.
LES Fat Frame components
Fork material
The fork on this frame is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Sizes
This frame is available in 3 sizes. They vary from 162 cm – 188 cm (5.31 ft – 6.17 ft). In conclusion, finding one for you shouldn’t be a problem.
