Pivot Mach 4 Carbon Frame Kit 2020
2020 Mountain
Estimate price |
4,499$
Bike details
Overview
Key information split into simple groups.
Frame summary
-
Category -
Frame Carbon -
Wheels 27.5" -
Fork Fox Factory Float 34 -
Suspension Full
Sizing
Recommended size guide.
XS
147cm - 162cm
SM
162cm - 172cm
MD
172cm - 180cm
LG
180cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Mach 4 Carbon
Suspension Fork
Fox Factory 34 27.5", 44mm offset, FIT4 - 130mm
Rear Shock
Fox Factory Float DPS
Cockpit
Headset
Pivot Precision Sealed Cartridge - Race
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | LL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.4 mm | 1.35 mm | 1.34 mm | 1.29 mm |
| Bottom Bracket Height | 325 mm | 325 mm | 325 mm | 325 mm | 325 mm |
| Stack | 552 mm | 571 mm | 577 mm | 589 mm | 599 mm |
| Reach | 394 mm | 408 mm | 426 mm | 441 mm | 466 mm |
| Top Tube Length | 557 mm | 585 mm | 605 mm | 624 mm | 647 mm |
| Seat Tube Angle | 73.8 ° | 73.25 ° | 73.25 ° | 73.25 ° | 73.6 ° |
| Seat Tube Length | 368 mm | 406 mm | 445 mm | 483 mm | mm |
| Head Tube Angle | 68.5 ° | 69.2 ° | 69.2 ° | 69.2 ° | 69.5 ° |
| Head Tube Length | 85 mm | 102 mm | 108 mm | 120 mm | 130 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1074 mm | 1087 mm | 1107 mm | 1124 mm | 1152 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 664 mm | 669 mm | 671 mm | 688 mm | 695 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 147 cm | 162 cm | 172 cm | 180 cm | cm |
| Rider Max Height | 162 cm | 172 cm | 180 cm | 188 cm | cm |
Model Overview
Mach 4 Carbon Frame Kit is a Pivot Mach 4 model. There are 180 frames that carry this model name. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
Pivot Mach 4 Carbon Frame 2020 is the most economical model, with a starting price of 3399$. Pivot Mach 4 SL Frame Kit w/ Fox Live Valve WC 2020 on the other hand costs 6599$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry frames
According to our math, the average price for a trustworthy Crosscountry frame is 1689$. However, this doesn’t mean that if you spend less money on a Crosscountry frame, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the frame and its components before buying it to ensure you don’t pay too much.
This frame was released in 2020 and its price was 4499$. In conclusion, this frame price is 166.37% higher than the price of the average Crosscountry frame.
Overview of components
Fork
The Mach 4 Carbon Frame Kit comes factory-installed with the Fox Factory Float 34 fork. This has a travel range of mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
