Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 203mm -
Fork Marzocchi Bomber 58
-
Groupset Zee -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
187cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Phoenix
Suspension Fork
Marzocchi Bomber 58 27.5", 52mm offset, GRIP - 203mm
Rear Shock
Fox Factory Float X2
Drivetrain
Rear Derailleur
Shimano Zee 10-Speed
Shift Levers
Shimano Zee M640 10-Speed
Cassette
Shimano 105 CS-5700 11-28t
Crank
Shimano Zee 36t - 165mm
Chain
Shimano CN-6701 10-Speed
Wheels
Rims
Sun Ringle ADD Comp
Tires
Maxxis Minion DHF 27.5" x 2.5" 3C, MAXXGRIP, DH CASINGMaxxis Minion DHRII 27.5" x 2.4" 3C, MAXXGRIP, DH CASING
Brakes
Brakes
Shimano Zee M640
Disk Rotors
Shimano SLX RT66 6-Bolt - 203mmShimano SLX RT66 6-Bolt - 203mm
Cockpit
Stem
Phoenix Team DH - 45mm
Handlebar
Phoenix Race Low Rise Aluminum - 800mm
Grips
Phoenix Team Padloc
Headset
Pivot Precision Sealed Cartridge - DH
Seat
Saddle
Phoenix WTB Race High Tail
Seatpost
Phoenix Race Aluminum
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.43 mm | 1.35 mm | 1.27 mm |
| Bottom Bracket Height | 340 mm | 340 mm | 340 mm | 340 mm |
| Stack | 608 mm | 608 mm | 608 mm | 608 mm |
| Reach | 397 mm | 425 mm | 452 mm | 479 mm |
| Top Tube Length | 600 mm | 626 mm | 651 mm | 677 mm |
| Seat Tube Angle | 71.85 ° | 71.85 ° | 71.85 ° | 71.85 ° |
| Seat Tube Length | 431 mm | 431 mm | 431 mm | 431 mm |
| Head Tube Angle | 62.5 ° | 62.5 ° | 62.5 ° | 62.5 ° |
| Head Tube Length | 106 mm | 106 mm | 106 mm | 106 mm |
| Chainstay Length | 439 mm | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1208 mm | 1235 mm | 1265 mm | 1288 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm | 15 mm |
| Standover Height | 734 mm | 734 mm | 734 mm | 734 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 162 cm | 171 cm | 179 cm | 187 cm |
| Rider Max Height | 174 cm | 182 cm | 189 cm | 200 cm |
About this model
Phoenix Zee belongs to the Pivot Phoenix model. Pivot launched 35 bikes of this model so far. You can easily view all of the Pivot Phoenix bikes models from 2019, here.
Model range prices
Pivot Phoenix Zee 2019 is the cheapest bike model and costs 3899$. Pivot Phoenix 29 Pro Saint 2019 is the most expensive one and costs 7599$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Downhill bikes
If you want to purchase a solid Downhill bike, it is important to know that the average cost is 3391$. However, even if your budget is less than the average, you might still be able to get a top-quality Downhill bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2019 for 3899$. If we compare this with the average Downhill bike cost we notice that the price is 14.98% higher.
Overview of components
Fork
Pivot Phoenix Zee 2019 bike is equipped with the Marzocchi Bomber 58 fork, and has 203mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When leaving the production line, the Phoenix Zee model has 27.5″ aluminum wheels. These wheels will provide you with more control over the bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Pivot Phoenix Zee has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 162 cm – 200 cm (5.31 ft – 6.56 ft). In conclusion, finding one for you shouldn’t be a problem.
