Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 140mm -
Fork Fox Factory Float 36
-
Groupset XT Di2 -
Suspension Full -
Motor Shimano 250W 70Nm mid-drive -
Battery BT-E8010 -
Drivetrain 1 × 11 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
187cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX 36 Factory 29/27.5+, 110mm quick-release axle
Rear Shock
FOX Float Factory DPX2 EVOL
Drivetrain
Rear Derailleur
Shimano XT Di2 11-speed GS
Front Derailleur
N/A
Shift Levers
XT Di2 11-speed (right) / E8000 (left)
Cassette
Shimano XT M8000, 11-46 tooth, 11-speed
Crank
FC-E8050 Hollowtech
Chain Guide
Top guide
Pedals
None
Wheels
Front Hub
DT Swiss/Pivot Custom EB1550 40mm eMTB specific design wheels
Rear Hub
DT Swiss/Pivot Custom EB1550 40mm eMTB specific design wheels
Rims
DT Swiss/Pivot Custom EB1550 40mm eMTB specific design wheels
Spokes
DT Swiss/Pivot Custom EB1550 40mm eMTB specific design wheels
Tires
Maxxis Rekon, 27.5+ x 2.8", tubeless ready, 120 TPI, Silk-Shield
Brakes
Brakes
Shimano XT M8000, 203mm front disc, 180mm rear post-mount disc
Brake Levers
Shimano XT M8000
Cockpit
Stem
Phoenix Team Enduro/Trail
Handlebar
Phoenix Team Carbon, 35mm diameter, 760mm width
Grips
Phoenix Team Padloc
Headset
Pivot Precision Sealed Cartridge
Seat
Saddle
Phoenix WTB Vigo Pro
Seatpost
FOX Transfer dropper, 125mm travel (size S), 150mm travel (sizes M,L, and XL)
Motor & Battery
Motor
Shimano Steps E8000 eMTB system
Battery
BT-E8010
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.38 mm | 1.34 mm | 1.29 mm |
| Bottom Bracket Height | 348 mm | 348 mm | 348 mm | 348 mm |
| Stack | 596.4 mm | 605.6 mm | 614.7 mm | 623.9 mm |
| Reach | 418.6 mm | 438.7 mm | 458.8 mm | 483.7 mm |
| Top Tube Length | 591.6 mm | 614.2 mm | 636.8 mm | 664.3 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 393.7 mm | 425.5 mm | 457.2 mm | 495.3 mm |
| Head Tube Angle | 65.8 ° | 65.8 ° | 65.8 ° | 65.8 ° |
| Head Tube Length | 110 mm | 119.9 mm | 130 mm | 140 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1178 mm | 1202 mm | 1226 mm | 1255 mm |
| Bottom Bracket Drop | 7 mm | 7 mm | 7 mm | 7 mm |
| Standover Height | 699 mm | 699 mm | 706 mm | 710 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 162 cm | 171 cm | 179 cm | 187 cm |
| Rider Max Height | 174 cm | 182 cm | 189 cm | 200 cm |
Model Overview
Shuttle Europe is a Pivot E Shuttle model. 14 e-bikes variations carry this model name so far. You can get a glimpse at all models from 2018, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail e-bikes average price
Our math shows that the average cost of a dependable Trail e-bike is 3365$. However, you could also get a good Trail e-bike even if you pay a lower amount than the average price. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Average weight for Trail e-bikes
If we make a quick analysis of the average weight of a Trail e-bike, we get 23.7 kg (52.25 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Shuttle Europe weighs 19.95 kg (43.98 lbs) and is much lighter than the average. In short, the average Trail e-bike weight is 18.8% higher than this one.
Shuttle Europe components
Fork
The fork installed on this bike is the Fox Factory Float 36 model. The travel on this model is 150mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
As for the rear shock, this e-bike has the FOX Float Factory DPX2 EVOL model, with a travel of 140mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
When it comes to wheels, the Shuttle Europe e-bike is equipped with the 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Pivot Shuttle Europe has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 162 cm – 200 cm (5.31 ft – 6.56 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Pivot Shuttle Europe comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
