Pivot TRAIL 429 Pro X01 w/ Carbon Wheels 2022
2022 Mountain
Estimate price |
9,349$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Fox Factory Float 34
-
Groupset X01 Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS Low
147cm - 164cm
XS Low
147cm - 164cm
SM Low
161cm - 174cm
SM Low
161cm - 174cm
MD Low
171cm - 182cm
MD Low
171cm - 182cm
LG Low
179cm - 189cm
LG Low
179cm - 189cm
XL Low
187cm - 200cm
XL Low
187cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Trail 429
Suspension Fork
Fox Factory 34 29", GRIP2 - 130mm
Rear Shock
Fox Factory DPS
Drivetrain
Rear Derailleur
SRAM X01 Eagle 12-Speed
Shift Levers
SRAM X01 Eagle 12-Speed
Cassette
SRAM XG-1275 10-52t
Crank
SRAM X01 Eagle DUB 32t
Chain
SRAM X01 Eagle 12-Speed
Wheels
Rims
Reynolds Blacklabel 309/289 w/ Industry Nine Hydra hub 30mm F 28mm R - 29" 15x110 F/12x157 R
Tires
Maxxis Dissector 29" x 2.4" WT, TR, 3C, EXO, MAXXTERRA Maxxis Dissector 29" x 2.4" WT, TR, 3C, EXO, MAXXTERRA
Brakes
Brakes
SRAM G2 RSC 4-piston
Disk Rotors
SRAM Centerline CenterLock - 180mmSRAM Centerline CenterLock - 180mm
Cockpit
Stem
Phoenix Team Enduro/Trail
Handlebar
Phoenix Team Low Rise Carbon - 780mm
Grips
Phoenix Factory Lock-On
Headset
Pivot Precision Sealed Cartridge
Seat
Saddle
Phoenix WTB Volt Pro (Medium Width)
Seatpost
Fox Transfer Factory Series 125mm (XS), 125mm (SM), 150mm (MD) 175mm (LG) 200mm (XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS Low | XS Low | SM Low | SM Low | MD Low | MD Low | LG Low | LG Low | XL Low | XL Low |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.46 mm | 1.38 mm | 1.41 mm | 1.32 mm | 1.34 mm | 1.29 mm | 1.31 mm | 1.26 mm | 1.28 mm |
| Bottom Bracket Height | 347 mm | 340 mm | 347 mm | 340 mm | 347 mm | 340 mm | 347 mm | 340 mm | 347 mm | 340 mm |
| Front Center | 699 mm | 699 mm | 723 mm | 723 mm | 758 mm | 758 mm | 775 mm | 775 mm | 800 mm | 800 mm |
| Rake | 43 mm | 42 mm | 43 mm | 42 mm | 43 mm | 42 mm | 43 mm | 42 mm | 43 mm | 42 mm |
| Trail | 116 mm | 121 mm | 116 mm | 121 mm | 116 mm | 121 mm | 116 mm | 121 mm | 116 mm | 121 mm |
| Stack | 578 mm | 582 mm | 587 mm | 591 mm | 598 mm | 602 mm | 603 mm | 607 mm | 615 mm | 619 mm |
| Reach | 404 mm | 399 mm | 424 mm | 419 mm | 454 mm | 449 mm | 469 mm | 464 mm | 489 mm | 484 mm |
| Top Tube Length | 566 mm | 567 mm | 589 mm | 590 mm | 622 mm | 623 mm | 638 mm | 639 mm | 661 mm | 663 mm |
| Seat Tube Angle | 75.5 ° | 75 ° | 75.5 ° | 75 ° | 75.5 ° | 75 ° | 75.5 ° | 75 ° | 75.5 ° | 75 ° |
| Seat Tube Length | 343 mm | 343 mm | 368 mm | 368 mm | 394 mm | 394 mm | 432 mm | 432 mm | 470 mm | 470 mm |
| Head Tube Angle | 66.5 ° | 66 ° | 66.5 ° | 66 ° | 66.5 ° | 66 ° | 66.5 ° | 66 ° | 66.5 ° | 66 ° |
| Head Tube Length | 85 mm | 85 mm | 95 mm | 95 mm | 107 mm | 107 mm | 112 mm | 112 mm | 125 mm | 125 mm |
| Chainstay Length | 424 mm | 426 mm | 424 mm | 426 mm | 424 mm | 426 mm | 424 mm | 426 mm | 424 mm | 426 mm |
| Wheelbase | 1122 mm | 1123 mm | 1146 mm | 1147 mm | 1181 mm | 1182 mm | 1198 mm | 1199 mm | 1223 mm | 1224 mm |
| Bottom Bracket Drop | 27 mm | 33 mm | 27 mm | 33 mm | 27 mm | 33 mm | 27 mm | 33 mm | 27 mm | 33 mm |
| Standover Height | 630 mm | 625 mm | 662 mm | 656 mm | 664 mm | 658 mm | 676 mm | 671 mm | 690 mm | 684 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 147 cm | 147 cm | 161 cm | 161 cm | 171 cm | 171 cm | 179 cm | 179 cm | 187 cm | 187 cm |
| Rider Max Height | 164 cm | 164 cm | 174 cm | 174 cm | 182 cm | 182 cm | 189 cm | 189 cm | 200 cm | 200 cm |
About this model
TRAIL 429 Pro X01 w/ Carbon Wheels is part of the Pivot Trail model. 85 bikes variations carry this model name so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Pivot TRAIL 429 Race XT 2022 is the most economical model, with a starting price of 5999$. Pivot TRAIL 429 Team XX1 AXS Live 2022 on the other hand costs 13299$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 9349$. Comparing the average cost of a Trail bike to this one, you will see that TRAIL 429 Pro X01 w/ Carbon Wheels price is 238.49% higher.
Overview of components
Fork
The TRAIL 429 Pro X01 w/ Carbon Wheels comes factory-installed with the Fox Factory Float 34 fork. This has a travel range of 130mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The TRAIL 429 Pro X01 w/ Carbon Wheels has a rear shock with a travel of 120mm. The model Fox Factory DPS is the one installed in this bike. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The TRAIL 429 Pro X01 w/ Carbon Wheels 2022 bike is equipped with 29″ carbon wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Pivot TRAIL 429 Pro X01 w/ Carbon Wheels bike has 10 sizes, in the range of 147 cm – 200 cm (4.82 ft – 6.56 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Pivot TRAIL 429 Pro X01 w/ Carbon Wheels comes with a dropper post. Therefore, climbing or descending will be a breeze.
