Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Fox Performance Float 34
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS Low
147cm - 164cm
XS Low
147cm - 164cm
SM Low
161cm - 174cm
SM Low
161cm - 174cm
MD Low
171cm - 182cm
MD Low
171cm - 182cm
LG Low
179cm - 189cm
LG Low
179cm - 189cm
XL Low
187cm - 200cm
XL Low
187cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Trail 429
Suspension Fork
Fox Performance 34 29", GRIP - 130mm
Rear Shock
Fox Performance Float DPS
Drivetrain
Rear Derailleur
Shimano XT M8100 SGS 12-Speed
Shift Levers
Shimano SLX M7100 ISPEC EV 12-Speed
Cassette
Shimano SLX M7100 10-51t
Crank
Race Face Ride 32t
Chain
Shimano CN-M7100 12-Speed
Wheels
Rims
DT Swiss M1900 w/ DT Swiss 370 hub, 30mm - 29" 15x110 F/12x157 R
Tires
Maxxis Dissector 29" x 2.4" WT, TR, 3C, EXO, MAXXTERRA Maxxis Dissector 29" x 2.4" WT, TR, 3C, EXO, MAXXTERRA
Brakes
Brakes
Shimano SLX M7120 4-piston
Disk Rotors
Shimano SLX 6-bolt - 180mmShimano SLX 6-bolt - 180mm
Cockpit
Stem
Phoenix Team Enduro/Trail
Handlebar
Phoenix Race Low Rise Aluminum - 780mm
Grips
Phoenix Factory Lock-On
Headset
Pivot Precision Sealed Cartridge
Seat
Saddle
Phoenix WTB Volt Race (Medium Width)
Seatpost
Fox Transfer Performance Elite 100mm (XS), 125mm (SM), 150mm (MD) 175mm (LG), 200mm (XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS Low | XS Low | SM Low | SM Low | MD Low | MD Low | LG Low | LG Low | XL Low | XL Low |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.46 mm | 1.38 mm | 1.41 mm | 1.32 mm | 1.34 mm | 1.29 mm | 1.31 mm | 1.26 mm | 1.28 mm |
| Bottom Bracket Height | 347 mm | 340 mm | 347 mm | 340 mm | 347 mm | 340 mm | 347 mm | 340 mm | 347 mm | 340 mm |
| Front Center | 699 mm | 699 mm | 723 mm | 723 mm | 758 mm | 758 mm | 775 mm | 775 mm | 800 mm | 800 mm |
| Rake | 43 mm | 42 mm | 43 mm | 42 mm | 43 mm | 42 mm | 43 mm | 42 mm | 43 mm | 42 mm |
| Trail | 116 mm | 121 mm | 116 mm | 121 mm | 116 mm | 121 mm | 116 mm | 121 mm | 116 mm | 121 mm |
| Stack | 578 mm | 582 mm | 587 mm | 591 mm | 598 mm | 602 mm | 603 mm | 607 mm | 615 mm | 619 mm |
| Reach | 404 mm | 399 mm | 424 mm | 419 mm | 454 mm | 449 mm | 469 mm | 464 mm | 489 mm | 484 mm |
| Top Tube Length | 566 mm | 567 mm | 589 mm | 590 mm | 622 mm | 623 mm | 638 mm | 639 mm | 661 mm | 663 mm |
| Seat Tube Angle | 75.5 ° | 75 ° | 75.5 ° | 75 ° | 75.5 ° | 75 ° | 75.5 ° | 75 ° | 75.5 ° | 75 ° |
| Seat Tube Length | 343 mm | 343 mm | 368 mm | 368 mm | 394 mm | 394 mm | 432 mm | 432 mm | 470 mm | 470 mm |
| Head Tube Angle | 66.5 ° | 66 ° | 66.5 ° | 66 ° | 66.5 ° | 66 ° | 66.5 ° | 66 ° | 66.5 ° | 66 ° |
| Head Tube Length | 85 mm | 85 mm | 95 mm | 95 mm | 107 mm | 107 mm | 112 mm | 112 mm | 125 mm | 125 mm |
| Chainstay Length | 424 mm | 426 mm | 424 mm | 426 mm | 424 mm | 426 mm | 424 mm | 426 mm | 424 mm | 426 mm |
| Wheelbase | 1122 mm | 1123 mm | 1146 mm | 1147 mm | 1181 mm | 1182 mm | 1198 mm | 1199 mm | 1223 mm | 1224 mm |
| Bottom Bracket Drop | 27 mm | 33 mm | 27 mm | 33 mm | 27 mm | 33 mm | 27 mm | 33 mm | 27 mm | 33 mm |
| Standover Height | 630 mm | 625 mm | 662 mm | 656 mm | 664 mm | 658 mm | 676 mm | 671 mm | 690 mm | 684 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 147 cm | 147 cm | 161 cm | 161 cm | 171 cm | 171 cm | 179 cm | 179 cm | 187 cm | 187 cm |
| Rider Max Height | 164 cm | 164 cm | 174 cm | 174 cm | 182 cm | 182 cm | 189 cm | 189 cm | 200 cm | 200 cm |
About this model
Trail 429 Race XT belongs to the Pivot Trail model. Pivot released 85 bikes variations of this model so far. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
Pivot Trail 429 Race XT 2021 is the most economical model, with a starting price of 5899$. Pivot Trail 429 Team XX1 AXS Live 2021 on the other hand costs 13099$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5899$. Comparing the average cost of a Trail bike to this one, you will see that Trail 429 Race XT price is 113.58% higher.
Trail 429 Race XT components
Fork
The Trail 429 Race XT comes factory-installed with the Fox Performance Float 34 fork. This has a travel range of 130mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this bike is Fox Performance Float DPS, with a travel distance of 120mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When it comes to wheels, the Trail 429 Race XT bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. Pivot Trail 429 Race XT has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This bike is available in 10 sizes. They vary from 147 cm – 200 cm (4.82 ft – 6.56 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Every bike should have a dropper post, and this one does. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
