Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force eTap, Force 1 -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
147cm - 164cm
SM
161cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
187cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Vault
Suspension Fork
Pivot Vault Carbon
Drivetrain
Rear Derailleur
SRAM Force AXS e-Tap 12-Speed
Shift Levers
SRAM Force AXS eTap 12-Speed
Cassette
SRAM XG-1270 10-36t
Crank
SRAM Force 1 DUB 38t
Chain
SRAM Force Flattop 12-Speed
Wheels
Rims
DT Swiss CR 1600 SPLINE 22mm - 700C 12x100 F/12x142 R
Tires
Maxxis Rambler 700c x 40mm TR Tan Wall EXOMaxxis Rambler 700c x 40mm TR Tan Wall EXO
Brakes
Brakes
SRAM Force e-Tap AXS 2-piston
Disk Rotors
SRAM Centerline CenterLock - 160mmSRAM Centerline CenterLock - 160mm
Cockpit
Stem
Phoenix Team 31.8mm
Handlebar
Easton EC70 AX Carbon - 40cm (XS), 42cm (SM), 44cm (MD), 46cm (LG, XL)
Headset
Pivot Precision Sealed Integrated Cartridge
Seat
Saddle
Phoenix WTB Team Volt
Seatpost
Phoenix Pro ISO Flex Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.43 mm | 1.45 mm | 1.47 mm | 1.52 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 590 mm | 592 mm | 610 mm | 618 mm | 628 mm |
| Rake | 45 mm | 44 mm | 45 mm | 45 mm | 45 mm |
| Trail | 79 mm | 70 mm | 66 mm | 66 mm | 66 mm |
| Stack | 527 mm | 556 mm | 581 mm | 596 mm | 619 mm |
| Reach | 381 mm | 388 mm | 402 mm | 405 mm | 407 mm |
| Top Tube Length | 522 mm | 545 mm | 572 mm | 585 mm | 597 mm |
| Seat Tube Angle | 74.8 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 458 mm | 528 mm | 548 mm | 568 mm | 588 mm |
| Head Tube Angle | 70 ° | 71.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 105 mm | 130 mm | 155 mm | 170 mm | 195 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1007 mm | 1009 mm | 1027 mm | 1035 mm | 1045 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 712 mm | 773 mm | 794 mm | 812 mm | 832 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 147 cm | 161 cm | 171 cm | 179 cm | 187 cm |
| Rider Max Height | 164 cm | 174 cm | 182 cm | 189 cm | 200 cm |
About this model
VAULT Team Force is part of the Pivot Vault model. Pivot launched 27 bikes of this model so far. Take a sneak peek at all Pivot Vault bikes models from 2022, by clicking here.
Model range prices
Pivot VAULT Pro GRX 2022 is the most economical model, with a starting price of 6051$. Pivot VAULT Team Force/X01 Wide Range w/ Carbon Wheels 2022 on the other hand costs 8971$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel bikes average price
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 7803$. Comparing the average cost of a Gravel bike to this one, you will see that VAULT Team Force price is 216.94% higher.
VAULT Team Force components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
As for the wheels, Pivot VAULT Team Force 2022, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Pivot VAULT Team Force has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This bike is available in 5 sizes. They vary from 147 cm – 200 cm (4.82 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
