planetx Planet X XLS EVO SRAM Force 1 Carbon 2023
2023 Road
Estimate price |
2,979$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Force -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
160cm - 167cm
SM
165cm - 172cm
MD
169cm - 178cm
LG
175cm - 188cm
XL
185cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Drivetrain
Rear Derailleur
SRAM Force 1 Rear Mech / 11 Speed / Long Cage
Cassette
SRAM PG1130 Cassette / 11-42T
Crank
SRAM Force 1 GXP Chainset (No BB) / 172.5mm / 42T
Bottom Bracket
SRAM GXP XR Bottom Bracket (With Spacers) / 68/73mm
Chain
SRAM PC1110 11 Speed Chain / 116 Links
Wheels
Rims
Fulcrum Rapid Red 900 700c Disc Centrelock Clincher Wheelset / Shimano 11 Speed
Tires
Panaracer Comet Hardpack Wire Bead Tyre / 700c / 33mm / Black
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
Selcof Zeta 6061 Alloy Stem / 100mm / 31.8mm / 7 Degree
Handlebar
Selcof Zeta V3 Alloy Road Bar / 42cm
Seat
Saddle
San Marco Monza Start Saddle / Black / Carbon Steel
Seatpost
Selcof Zeta 6061 Alloy Seatpost / 27.2mm / 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.46 mm | 1.49 mm | 1.52 mm | 1.54 mm |
| Bottom Bracket Height | 280 mm | 280 mm | 280 mm | 280 mm | 280 mm |
| Front Center | 590 mm | 591 mm | 591 mm | 601 mm | 616 mm |
| Rake | 45 mm | 44 mm | 45 mm | 45 mm | 46 mm |
| Trail | 71 mm | 68 mm | 64 mm | 64 mm | 63 mm |
| Stack | 539 mm | 558 mm | 569 mm | 588 mm | 607 mm |
| Reach | 382 mm | 382 mm | 383 mm | 387 mm | 395 mm |
| Top Tube Length | 525 mm | 539 mm | 550 mm | 565 mm | 580 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 110 mm | 130 mm | 140 mm | 160 mm | 180 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1012 mm | 1012 mm | 1013 mm | 1023 mm | 1038 mm |
| Bottom Bracket Drop | 64 mm | 64 mm | 64 mm | 64 mm | 64 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 165 cm | 169 cm | 175 cm | 185 cm |
| Rider Max Height | 167 cm | 172 cm | 178 cm | 188 cm | 193 cm |
Model Overview
XLS EVO SRAM Force 1 Carbon completes the Planetx Xls model. Planet X launched 9 bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Planet X XLS EVO SRAM Rival 1 Carbon 2023 is the cheapest bike model and costs 2310$. Planet X XLS EVO SRAM Force 1 Carbon 2023 is the most expensive one and costs 2675$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Cyclocross bikes average price
According to our math, the average price for a trustworthy Cyclocross bike is 2012$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Cyclocross bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2023 and its price was 2675$. If we compare this with the average Cyclocross bike cost we notice that the price is 32.95% higher.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When it comes to wheels, the XLS EVO SRAM Force 1 Carbon bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The XLS EVO SRAM Force 1 Carbon has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
XLS EVO SRAM Force 1 Carbon comes in 5 sizes, that range from 160 cm – 193 cm (5.25 ft – 6.33 ft). In conclusion, it won’t take much to find one that’s right for you.
