Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 110mm -
Fork RockShox Recon Silver RL
-
Groupset GX Eagle, NX Eagle -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Recon RL, Boost, 15mm x 110mm
Rear Shock
RockShox Monarch RT3, 184mm x 44mm
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12-speed
Front Derailleur
None
Shift Levers
SRAM NX Eagle, 12-speed
Cassette
SRAM Eagle, 12-speed
Crank
SRAM NX Eagle, Boost
Bottom Bracket
SRAM DUB, 73mm threaded
Chain
SRAM Eagle, 12-speed
Chain Guide
OneUp Components
Pedals
None
Wheels
Front Hub
Mavic XA 29" wheelset, 15mm x 110mm, 148mm x 12mm
Rear Hub
Mavic XA 29" wheelset, 15mm x 110mm, 148mm x 12mm
Rims
Mavic XA 29" wheelset
Spokes
Mavic XA 29" wheelset
Tires
Maxxis Ikon 29" x 2.2", 3C, TR, EXO
Brakes
Brakes
SRAM Level, 160mm rotors
Brake Levers
SRAM Level
Cockpit
Stem
Race Face Chester, 40mm
Handlebar
Race Face Chester Riser, 35mm diameter
Grips
Race Face Love Handle
Headset
Cane Creek Forty, ZS44/ZS56
Seat
Saddle
Ergon
Seatpost
Race Face Ride
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.28 mm | 1.2 mm | 1.15 mm |
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm | 339 mm |
| Front Center | 785 mm | 815 mm | 845 mm | 870 mm |
| Rake | 58 mm | 58 mm | 58 mm | 58 mm |
| Trail | 111 mm | 111 mm | 111 mm | 111 mm |
| Stack | 618 mm | 618 mm | 618 mm | 618 mm |
| Reach | 453 mm | 483 mm | 513 mm | 538 mm |
| Top Tube Length | 587 mm | 617 mm | 647 mm | 672 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° | 78 ° |
| Seat Tube Length | 420 mm | 440 mm | 480 mm | 510 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 135 mm | 135 mm | 135 mm | 135 mm |
| Chainstay Length | 458 mm | 458 mm | 458 mm | 458 mm |
| Wheelbase | 1241 mm | 1271 mm | 1301 mm | 1326 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 721 mm | 721 mm | 721 mm | 721 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Evolink 110 TR is a Pole Evolink model. 25 bikes variations carry this model name so far. Take a sneak peek at all Pole Evolink bikes models from 2020, by clicking here.
Model range prices
Pole Evolink 110 TR 2020 is the most affordable bike of this model and has a price of 3150$. On the other hand, Pole Evolink 158 LE Coil 2020, is the most expensive and costs 8110$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Pole Evolink 110 TR price was 3150$. In conclusion, this bike price is 65.35% more expensive than the price of the average Crosscountry bike.
Overview of components
Fork
The Evolink 110 TR comes factory-installed with the RockShox Recon Silver RL fork. This has a travel range of 130mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
Pole Evolink 110 TR bike has the RockShox Monarch RT3 model installed, and has a travel of 110mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
As for the wheels, Pole Evolink 110 TR 2020, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Pole Evolink 110 TR has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Pole Evolink 110 TR bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
