Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Groupset Sora -
Suspension Rigid -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
150cm - 164cm
MD
162cm - 176cm
LG
174cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALX GRAVEL FRAME - CARRIER & FENDER READY
Suspension Fork
CARBON RIGID FORK W/FLATMOUNT - CARRIER & FENDER READY
Rear Shock
-
Drivetrain
Rear Derailleur
SHIMANO SORA RD-R3000
Shift Levers
SHIMANO SORA ST-R3000
Cassette
SHIMANO CS-HG200
Crank
ALLOY CRANKSET
Bottom Bracket
CARTRIDGE BB
Chain
KMC X9
Wheels
Rims
ALLOY DOUBLE WALL WHEELSET 32H
Tires
PERFORMANCE TIRE 650X47C TUBELESS READY
Brakes
Brakes
TEKTRO C400 MECHANICAL DISC BRAKE
Cockpit
Stem
ENTITY EXPERT, ALLOY
Handlebar
ENTITY EXPERT, ALLOY
Seat
Saddle
ENTITY SADDLE
Seatpost
ENTITY EXPERT, ALLOY
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.58 mm | 1.61 mm |
| Bottom Bracket Height | 261.5 mm | 261.5 mm | 261.5 mm |
| Front Center | 592 mm | 612 mm | 627 mm |
| Rake | 50 mm | 50 mm | 50 mm |
| Trail | 56 mm | 53 mm | 48 mm |
| Stack | 565.1 mm | 595.5 mm | 628 mm |
| Reach | 361 mm | 376 mm | 391 mm |
| Top Tube Length | 524.2 mm | 547.9 mm | 572.2 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 430 mm | 480 mm | 535 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72.5 ° |
| Head Tube Length | 140 mm | 170 mm | 200 mm |
| Chainstay Length | 416 mm | 416 mm | 416 mm |
| Wheelbase | 995 mm | 1015 mm | 1030 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 80 mm |
| Standover Height | 673 mm | 716 mm | 763 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 150 cm | 162 cm | 174 cm |
| Rider Max Height | 164 cm | 176 cm | 188 cm |
Model Overview
BEND R2 belongs to the Polygon Bend model. Polygon released 23 bikes variations of this model so far. Take a sneak peek at all Polygon Bend bikes models from 2020, by clicking here.
Model range prices
Polygon BEND R2 2020 is the most economical model, with a starting price of 919$. Polygon BEND R5 2020 on the other hand costs 1559$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Touring bikes
According to our math, the average price for a trustworthy Touring bike is 1007$. However, even if your budget is less than the average, you might still be able to get a top-quality Touring bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 919$. Comparing the average cost of a Touring bike to this one, you will see that BEND R2 price is 9.58% smaller.
BEND R2 components
Fork material
BEND R2 has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The BEND R2 2020 bike is equipped with aluminum wheels when leaving the factory. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The BEND R2 comes with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Polygon BEND R2 bike has 3 sizes, in the range of 150 cm – 188 cm (4.92 ft – 6.17 ft). In conclusion, it won’t take much to find one that’s right for you.
