Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Groupset Sora -
Suspension Rigid -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
150cm - 164cm
MD
162cm - 176cm
LG
174cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALX GRAVEL FRAME - CARRIER & FENDER READY
Suspension Fork
CARBON RIGID FORK W/FLATMOUNT - CARRIER & FENDER READY
Rear Shock
-
Drivetrain
Rear Derailleur
SHIMANO SORA RD-R3000
Shift Levers
SHIMANO SORA ST-R3000
Cassette
SHIMANO CS-HG200
Crank
ALLOY CRANKSET
Bottom Bracket
CARTRIDGE BB
Chain
KMC X9
Wheels
Rims
ALLOY DOUBLE WALL WHEELSET 32H
Tires
PERFORMANCE TIRE 650X47C TUBELESS READY
Brakes
Brakes
TEKTRO C400 MECHANICAL DISC BRAKE
Cockpit
Stem
ENTITY EXPERT, ALLOY
Handlebar
ENTITY EXPERT, ALLOY
Seat
Saddle
ENTITY SADDLE
Seatpost
ENTITY EXPERT, ALLOY
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.58 mm | 1.61 mm |
| Bottom Bracket Height | 261.5 mm | 261.5 mm | 261.5 mm |
| Front Center | 592 mm | 612 mm | 627 mm |
| Rake | 50 mm | 50 mm | 50 mm |
| Trail | 56 mm | 53 mm | 48 mm |
| Stack | 565.1 mm | 595.5 mm | 628 mm |
| Reach | 361 mm | 376 mm | 391 mm |
| Top Tube Length | 524.2 mm | 547.9 mm | 572.2 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 430 mm | 480 mm | 535 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72.5 ° |
| Head Tube Length | 140 mm | 170 mm | 200 mm |
| Chainstay Length | 416 mm | 416 mm | 416 mm |
| Wheelbase | 995 mm | 1015 mm | 1030 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 80 mm |
| Standover Height | 673 mm | 716 mm | 763 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 150 cm | 162 cm | 174 cm |
| Rider Max Height | 164 cm | 176 cm | 188 cm |
About this model
BEND R2 belongs to the Polygon Bend model. There are 23 bikes that carry this model name. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
Polygon BEND R2 2021 is the most economical model, with a starting price of 979$. Polygon BEND R5 2021 on the other hand costs 1649$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Touring bikes average price
If you want to purchase a solid Touring bike, it is important to know that the average cost is 1007$. However, you could also get a good Touring bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 979$. In conclusion, this bike price is 2.86% smaller than the price of the average Touring bike.
BEND R2 components
Fork material
The fork is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
The wheels on BEND R2 are the aluminum type. After 700c wheels, 650b is the second most popular choice for road bikes. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Polygon BEND R2 has Mechanical Disc brakes installed. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 150 cm – 188 cm (4.92 ft – 6.17 ft). In conclusion, finding one for you shouldn’t be a problem.
