Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
MD
162cm - 175cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUTECH XC SPORT 27.5"
Suspension Fork
SUNTOUR XCE, 100MM 27.5" TRAVEL
Rear Shock
-
Drivetrain
Rear Derailleur
SHIMANO RD-TY200 6/7-SPEED DA
Shift Levers
SHIMANO ST-EF41 3X7 SPEED
Cassette
SHIMANO TZ500 7-SPEED 14-28T
Crank
WHEELTOP TCSH2-CFPG 42/34/24T 170 MM
Bottom Bracket
CARTRIDGE BB
Chain
KMC HV-500 7-SPEED
Wheels
Rims
DOUBLE WALL ALLOY RIMS W/ ALLOY HUBS
Tires
PERFORMANCE TIRE 27.5" X2.1
Brakes
Brakes
TEKTRO MD-M280 DISC BRAKE
Cockpit
Stem
ENTITY OE E: 45MM, BB: 31.8MM
Handlebar
STEEL W:680MM R:40MM BB:31.8MM
Seat
Saddle
FOMING STEEL RAIL
Seatpost
STEEL CANDLE TYPE 27.2MMX300MM
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD |
|---|---|
| Stack Reach Ratio | 1.48 mm |
| Bottom Bracket Height | 303 mm |
| Front Center | 660 mm |
| Rake | 42 mm |
| Trail | 91 mm |
| Stack | 602.8 mm |
| Reach | 407.2 mm |
| Top Tube Length | 590 mm |
| Seat Tube Angle | 73 ° |
| Seat Tube Length | 456 mm |
| Head Tube Angle | 69 ° |
| Head Tube Length | 105 mm |
| Chainstay Length | 435 mm |
| Wheelbase | 1091 mm |
| Bottom Bracket Drop | 47 mm |
| Standover Height | 752 mm |
| Wheels | 27" |
| Rider Min Height | 162 cm |
| Rider Max Height | 175 cm |
Model Overview
CASCADE 2 completes the Polygon Cascade model. 15 bikes variations carry this model name so far. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Polygon CASCADE 2 2020 is the most affordable bike of this model and has a price of 429$. On the other hand, Polygon CASCADE 4 2020, is the most expensive and costs 549$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Polygon CASCADE 2 price was 429$. Comparing this to the average Crosscountry bike price, we see that the price is 344.06% smaller.
CASCADE 2 components
Fork
The SunTour is included from the factory. It has a travel distance of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The CASCADE 2 2020 bike is equipped with 27.5″ aluminum wheels when leaving the factory. These wheels will provide you with more control over the bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The CASCADE 2 comes with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Polygon CASCADE 2 2020 is available in one size only. In short, make sure you double-check if it fits you.
