Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 200mm -
Travel Rear 200mm -
Fork SunTour RUX
-
Groupset X0, e*thirteen LG1 Race -
Suspension Full -
Drivetrain 1 × 7 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
SR Suntour Rux
Rear Shock
FOX Factory Float X2
Drivetrain
Rear Derailleur
SRAM X0 DH, 7-speed
Front Derailleur
N/A
Shift Levers
SRAM X0 DH, 7-speed
Cassette
e*thirteen, direct mount, 7-speed, 9-21 tooth
Crank
e*thirteen LG1 Race Carbon, 165mm
Bottom Bracket
e*thirteen BSA, 83mm
Chain
KMC X-11SL
Chain Guide
Yes
Pedals
N/A
Wheels
Front Hub
e*thirteen LG1, integrated cassette
Rear Hub
e*thirteen LG1, integrated cassette
Rims
e*thirteen LG1 Race Carbon
Tires
Kenda Hellkat K1201, 27.5" x 2.40"
Brakes
Brakes
Trickstuff Direttissima
Brake Levers
Trickstuff Direttissima
Cockpit
Stem
Spank Director, 50mm length
Handlebar
Spank Spike Vibrocore, 800mm width, 30mm rise
Headset
FSA No. 57E
Seat
Saddle
Reverse Fort Will, titanium rail
Seatpost
KS Ether Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM High | MD High | LG High | XL High |
|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.429 mm | 1.358 mm | 1.285 mm |
| Bottom Bracket Height | 353.6 mm | 353.5 mm | 353.3 mm | 353.2 mm |
| Stack | 599.2 mm | 599.5 mm | 599.6 mm | 599.9 mm |
| Reach | 391.6 mm | 419.5 mm | 441.6 mm | 466.8 mm |
| Top Tube Length | 559 mm | 586.8 mm | 608.9 mm | 634 mm |
| Seat Tube Angle | 62.2 ° | 62.2 ° | 62.2 ° | 62.2 ° |
| Seat Tube Length | 383 mm | 383 mm | 383 mm | 383 mm |
| Head Tube Angle | 62.2 ° | 62.3 ° | 62.3 ° | 62.3 ° |
| Head Tube Length | 110 mm | 110 mm | 110 mm | 110 mm |
| Bottom Bracket Drop | 2 mm | 2 mm | 2 mm | 2 mm |
| Standover Height | 671 mm | 669 mm | 668 mm | 668 mm |
| Wheels | 27" | 27" | 27" | 27" |
Model Overview
Collosus DH Team belongs to the Polygon Collosus model. There are 20 bikes that carry this model name. Check out the entire range from 2018 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Downhill bikes average price
According to our calculations, the average cost of a Downhill bike that is reliable is 3391$. However, even though the average price of a Downhill bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork
The Collosus DH Team comes factory-installed with the SunTour RUX fork. This has a travel range of 200mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
From the factory, it comes with the FOX Factory Float X2 rear shock model, which has a travel of 200mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When leaving the production line, the Collosus DH Team model has 27.5″ carbon wheels. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Collosus DH Team comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
