Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Deore, Shimano -
Suspension Rigid -
Battery SHIMANO BT-E8010, 504W h -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
150cm - 161cm
MD
159cm - 170cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
aluminum
Suspension Fork
FULL CARBON RIGID FORK
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-6000SGS
Shift Levers
SHIMANO DEORE SL-6000-R
Cassette
SHIMANO DEORE CS-HG500, 11-34T
Crank
CHAINWHEEL SHIMANO FC-E5010 170MM (43-49MM) 175MM (52MM), CHAINRING SHIMANO SM-CRE50 44T
Bottom Bracket
(MID MOTOR) SHIMANO DRIVE UNIT DU-E5000
Chain
KMC X10E
Pedals
FLAT ALLOY PEDAL
Wheels
Rims
ALLOY DOUBLE WALL RIMS WITH ALLOY HUB (TUBELESS READY)
Tires
SCHWALBE SUPER MOTO-X 27.5”X2.40
Brakes
Brakes
SHIMANO BR-MT201
Cockpit
Handlebar
ENTITY XPERT, ALLOY, 700MM
Headset
ZS 44/28.6 | ZS 56/40
Seat
Saddle
ENTITY SADDLE, STEEL RAIL
Seatpost
ENTITY XPERT, ALLOY, 27.2X300MM
Motor & Battery
Battery
SHIMANO BT-E8010, 504W h
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.44 mm |
| Bottom Bracket Height | 287 mm | 287 mm |
| Front Center | 599 mm | 616 mm |
| Rake | 50 mm | 50 mm |
| Trail | 61 mm | 61 mm |
| Stack | 538 mm | 557 mm |
| Reach | 376 mm | 386 mm |
| Top Tube Length | 521 mm | 542 mm |
| Seat Tube Angle | 75 ° | 74.5 ° |
| Seat Tube Length | 430 mm | 460 mm |
| Head Tube Angle | 71 ° | 71 ° |
| Head Tube Length | 120 mm | 140 mm |
| Chainstay Length | 456 mm | 456 mm |
| Wheelbase | 1046 mm | 1063 mm |
| Bottom Bracket Drop | 70 mm | 70 mm |
| Standover Height | 521 mm | 524 mm |
| Wheels | 650 | 650 |
| Rider Min Height | 150 cm | 159 cm |
| Rider Max Height | 161 cm | 170 cm |
About this model
PATH E5 LADY completes the Polygon Path model. 30 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Polygon PATH 2 2023 is the cheapest bike model and costs 559$. Polygon PATH E5 LADY 2023 is the most expensive one and costs 2249$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Commuter bikes
If you want to purchase a solid Commuter bike, it is important to know that the average cost is 762$. However, even if your budget is less than the average, you might still be able to get a top-quality Commuter bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2249$. Doing a quick comparison, we notice that PATH E5 LADY price is 195.14% higher than the average cost of a Commuter bike.
Overview of components
Fork material
PATH E5 LADY has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The wheels on PATH E5 LADY are the aluminum type. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
Nothing is more important on a bike than its ability to brake properly. Polygon PATH E5 LADY is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 2 sizes. They vary from 150 cm – 170 cm (4.92 ft – 5.58 ft). In short, it won’t be difficult to find the right one for you.
