Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork SunTour XCM HLO
-
Groupset Sora, Altus -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 165cm
MD
162cm - 175cm
LG
172cm - 185cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUTECH XC SPORT FRAME
Suspension Fork
SUNTOUR XCM-HLO 120mm TRAVEL
Rear Shock
-
Drivetrain
Rear Derailleur
SHIMANO M3100
Shift Levers
SHIMANO M2010 ALTUS
Cassette
SHIMANO CS-HG200
Crank
ALLOY TN-CY10
Bottom Bracket
CARTRIDGE BB
Chain
KMC X9
Wheels
Rims
DOUBLE WALL ALLOY RIMS W/ ALLOY HUBS
Tires
PERFORMANCE TIRE 27.5" X 2.10"
Brakes
Brakes
TEKTRO M275 HYDRAULIC DISC BRAKE
Cockpit
Stem
ENTITY SPORT, ALLOY
Handlebar
ENTITY SPORT, ALLOY
Seat
Saddle
ENTITY VOID
Seatpost
ENTITY SPORT, ALLOY
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.52 mm | 1.47 mm |
| Bottom Bracket Height | 299 mm | 299 mm | 299 mm |
| Front Center | 646 mm | 661 mm | 681 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 91 mm | 91 mm | 91 mm |
| Stack | 616 mm | 616 mm | 621 mm |
| Reach | 389.5 mm | 404.5 mm | 423 mm |
| Top Tube Length | 576 mm | 591 mm | 611 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 406 mm | 456 mm | 506 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 100 mm | 100 mm | 105 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1078 mm | 1093 mm | 1113 mm |
| Bottom Bracket Drop | 47 mm | 47 mm | 47 mm |
| Standover Height | 719 mm | 759 mm | 799 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 152 cm | 162 cm | 172 cm |
| Rider Max Height | 165 cm | 175 cm | 185 cm |
About this model
PREMIER 5 belongs to the Polygon Premier model. There are 39 bikes that carry this model name. Take a sneak peek at all Polygon Premier bikes models from 2020, by clicking here.
Model range prices
Polygon PREMIER 4 2020 is the most economical model, with a starting price of 599$. Polygon PREMIER 5 2020 on the other hand costs 699$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Polygon PREMIER 5 price was 699$. Doing a quick comparison, we notice that PREMIER 5 price is 295.14% smaller than the average cost of a Trail bike.
Overview of components
Fork
Polygon PREMIER 5 2020 bike is equipped with the SunTour XCM HLO fork, and has 120mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on PREMIER 5 are the 27.5″ aluminum type. The 27.5″ wheels are a great choice for smaller riders. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Polygon PREMIER 5 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This bike is available in 3 sizes. They vary from 152 cm – 185 cm (4.99 ft – 6.07 ft). In short, it won’t be difficult to find the right one for you.
