Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 170mm -
Travel Rear 165mm -
Fork Öhlins RXF38
-
Groupset X01 -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
168cm - 182cm
LG
178cm - 192cm
XL
188cm - 202cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
PRIME THUNDERFLASH 29” | 165 mm VIP COMPOSITES S.H.R.E.D DYNAMICS FULL CARBON FIBER FRAME INCLUDING FRONT TRIANGLE | REAR TRIANGLE UPPER LINK | LOWER LINK 205 x 65 mm SHOCK BSA 73 mm BOTTOM BRACKET 12 x 148 mm BOOST REAR AXLE 31,6 mm SEATPOST
Suspension Fork
ÖHLINS RXF 38 M.2 29” | 170 MM | TTX18 TWIN TUBE CARTRIDGE HSC, LSC, REBOUND | AIR PRELOUD | RAMP UP CHAMPER 15 X 110 MM | 44 MM RAKE
Rear Shock
ÖHLINS TTX 2 AIR AIR HSC, LSC, REBOUND | CLIMB MODE 205 x 65 mm
Drivetrain
Rear Derailleur
SRAM X01 12 Speed Eagle
Shift Levers
SRAM X01 12 Speed Eagle
Cassette
SRAM X01 XG-1295 | 10 - 50T | 12 Speed Eagle
Crank
SRAM X01 CARBON FIBER 170 mm | 30T | DUB
Bottom Bracket
SRAM DUB BSA | 68/73 mm
Chain
SRAM X01 12 Speed Eagle
Chain Guide
E13 TRS+ ISCG05 | 28-30T | BASH ONLY
Wheels
Front Hub
INDUSTRY NINE HYDRA 15 X 110 MM | 6B
Rear Hub
INDUSTRY NINE HYDRA 12 X 148 MM | 6B 0,52° ENGAGEMENT
Rims
INDUSTRY NINE 29” | 30,5 MM INTERNAL RIM WIDTH 28 Spokes
Tires
Front: MAXXIS ASSEGAI 29” x 2.50 | EXO+ | MAXXGRIP, Rear: MAXXIS ASSEGAI 29” x 2.50 | EXO+ | MAXXGRIP
Brakes
Brakes
Front: SRAM G2 RSC SRAM HS2 200 MM ROTOR, Rear: SRAM G2 RSC SRAM HS2 200 MM ROTOR
Cockpit
Stem
RENTHAL APEX 35 40 mm length
Handlebar
RENTHAL FATBAR CARBON 35 800 mm width | 30 mm rise
Grips
ODI ELITE PRO V 2.1 LOCK - ON | 130 mm
Headset
ACROS PRIME EDITION ZS44 / ZS56 BLOCK LOCK
Seat
Saddle
SDG BEL AIR 2.0 PRIME EDITION
Seatpost
BIKE YOKE REVIVE 160 mm (M) | 185 mm (L) | 213 mm (XL)
Motor & Battery
Remote
BIKE YOKE TRIGGY ALPHA SHORT
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.34 mm | 1.3 mm | 1.25 mm |
| Bottom Bracket Height | 346 mm | 346 mm | 346 mm |
| Front Center | 798 mm | 822 mm | 851 mm |
| Rake | 23 mm | 23 mm | 23 mm |
| Trail | 157 mm | 157 mm | 157 mm |
| Stack | 623 mm | 632 mm | 640 mm |
| Reach | 466 mm | 486 mm | 511 mm |
| Top Tube Length | 608 mm | 630 mm | 657 mm |
| Seat Tube Angle | 77.6 ° | 77.8 ° | 78 ° |
| Seat Tube Length | 423 mm | 443 mm | 473 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 451 mm | 451 mm | 451 mm |
| Wheelbase | 1249 mm | 1273 mm | 1302 mm |
| Bottom Bracket Drop | -25 mm | -25 mm | -25 mm |
| Standover Height | 776 mm | 774 mm | 770 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 168 cm | 178 cm | 188 cm |
| Rider Max Height | 182 cm | 192 cm | 202 cm |
Model Overview
Thunderflash R is a Prime Thunderflash model. Prime launched 4 bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
The most economical model, the Prime Thunderflash C 2023 has a starting price of 7999$. Prime Thunderflash R 2023 on the other hand is the most expensive at 8999$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Enduro bikes
If you want an acceptable Enduro bike you should know that the average price is 3599$. However, you could also get a good Enduro bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 8999$. If we compare this with the average Enduro bike cost we notice that the price is 150.04% higher.
Overview of components
Fork
Prime Thunderflash R 2023 bike is equipped with the Öhlins RXF38 fork, and has 170mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
From the factory, it comes with the ÖHLINS TTX 2 AIR AIR HSC rear shock model, which has a travel of 165mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
As for the wheels, Prime Thunderflash R 2023, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Thunderflash R comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 168 cm – 202 cm (5.51 ft – 6.63 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Prime Thunderflash R comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
