Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Titanium
Suspension Fork
Principia gravel tapered carbon fork, 12x100 (max 700x50C)
Drivetrain
Rear Derailleur
Shimano GRX RX810
Front Derailleur
Shimano GRX RX810
Shift Levers
Shimano GRX ST-RX600 2x11
Cassette
Shimano CS-HG700 11sp 11-34T
Crank
Shimano FC-RX600 46/30T 170mm
Chain
Shimano CN-HG601-11
Pedals
Not included
Wheels
Rims
LiTE Gravel w. thru axle, tubeless ready
Tires
Panaracer GravelKing SK 700x38C
Brakes
Brakes
Front: Shimano BR-RX400 hydraulic disc brake, 160 mm. rotor, Rear: Shimano BR-RX400 hydraulic disc brake, 160 mm. rotor
Cockpit
Stem
Ritchey Comp 4-Axis-44 6D Aluminium, 31,8x90mm
Handlebar
Ritchey Comp VentureMax, 31.8 mm/440 mm
Grips
Principia bar tape
Seat
Saddle
Ritchey Comp Streem
Seatpost
Ritchey Comp 2-Bolt Aluminium, 27,2x400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.56 mm | 1.56 mm | 1.56 mm | 1.57 mm |
| Bottom Bracket Height | 280 mm | 285 mm | 285 mm | 285 mm | 285 mm |
| Front Center | 591 mm | 603 mm | 613 mm | 629 mm | 645 mm |
| Rake | 53 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Stack | 548 mm | 571 mm | 587 mm | 602 mm | 621 mm |
| Reach | 361 mm | 366 mm | 376 mm | 386 mm | 396 mm |
| Top Tube Length | 523 mm | 543 mm | 558 mm | 573 mm | 588 mm |
| Seat Tube Angle | 74 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 109 mm | 135 mm | 150 mm | 165 mm | 185 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1011 mm | 1025 mm | 1035 mm | 1051 mm | 1067 mm |
| Bottom Bracket Drop | 80 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 776 mm | 799 mm | 817 mm | 833 mm | 852 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
22TiTAN G2 is a Principia 22titan model. There are 12 bikes that carry this model name. Take a sneak peek at all Principia 22titan bikes models from 2023, by clicking here.
Model range prices
Principia 22TiTAN G1 2023 is the most affordable bike of this model and has a price of 4777$. On the other hand, Principia 22TiTAN G2HC 2023, is the most expensive and costs 7113$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Principia released this model in 2023, its price was 4777$. Comparing the average cost of a Gravel bike to this one, you will see that 22TiTAN G2 price is 94.03% more expensive.
22TiTAN G2 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
The 22TiTAN G2 2023 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Principia 22TiTAN G2 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Principia 22TiTAN G2 bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
