Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 140mm -
Fork DVO Sapphire 32
-
Groupset GX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Chromoly
Suspension Fork
DVO Sapphire D1
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM GX Eagle, 12-speed
Cassette
SRAM GX Eagle, 12-speed, 10-50 tooth
Crank
SRAM GX Eagle DUB, 170mm length
Bottom Bracket
SRAM DUB, BB92 PressFit
Chain
SRAM GX Eagle, 12-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Spank Custom Tuned 350/359 wheelset, j-bend, 110x15mm Boost front, 148x12mm Boost rear with XD driver
Rear Hub
Spank Custom Tuned 350/359 wheelset, j-bend, 110x15mm Boost front, 148x12mm Boost rear with XD driver
Rims
Spank Custom Tuned 350/359 wheelset
Spokes
Spank Custom Tuned 350/359 wheelset, j-bend
Tires
Panaracer Aliso, TR, 3Comp, 29" x 2.4"
Brakes
Brakes
Magura MT Trail Sport, Magura Storm HC rotors (180mm front, 160mm rear)
Brake Levers
Magura MT Trail Sport
Cockpit
Stem
Production Privee R2R, 50mm length
Handlebar
Production Privee LGB, 780mm width
Grips
Production Privee CR35 adjustable
Headset
IS42 upper, IS52 lower
Seat
Saddle
fi'zi:k Taiga Enduro, alloy rails
Seatpost
Crankbrothers Highline dropper, 150mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.664 mm | 1.592 mm | 1.514 mm | 1.448 mm |
| Bottom Bracket Height | 316 mm | 316 mm | 316 mm | 316 mm |
| Front Center | 693 mm | 713 mm | 739 mm | 764 mm |
| Rake | 51 mm | 49 mm | 49 mm | 49 mm |
| Trail | 106 mm | 109 mm | 109 mm | 109 mm |
| Stack | 639 mm | 643 mm | 648 mm | 653 mm |
| Reach | 384 mm | 404 mm | 428 mm | 451 mm |
| Top Tube Length | 570 mm | 590 mm | 615 mm | 640 mm |
| Seat Tube Angle | 73.7 ° | 73.7 ° | 73.7 ° | 73.7 ° |
| Seat Tube Length | 400 mm | 430 mm | 460 mm | 490 mm |
| Head Tube Angle | 66.6 ° | 66.6 ° | 66.6 ° | 66.6 ° |
| Head Tube Length | 105 mm | 105 mm | 110 mm | 115 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1114 mm | 1134 mm | 1160 mm | 1185 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm | 58 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Shan GT Classic belongs to the Productionprivee Shan model. 53 bikes variations carry this model name so far. You can easily view all of the Productionprivee Shan bikes models from 2020, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Shan GT Classic components
Fork
Production Privee Shan GT Classic 2020 bike is equipped with the DVO Sapphire 32 fork, and has 140mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
As for the wheels, Production Privee Shan GT Classic 2020, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Production Privee Shan GT Classic has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
