Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 150mm -
Travel Rear 140mm -
Fork Cane Creek HELM
-
Groupset XX1 Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Chromoly
Suspension Fork
Cane Creek Helm
Rear Shock
Cane Creek DB Air, Climb Switch, 210mm x 55mm
Drivetrain
Rear Derailleur
SRAM XX1 Eagle, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM XX1 Eagle, 12-speed
Cassette
SRAM XX1 Eagle, 12-speed, 10-50 tooth, Gold finish
Crank
SRAM XX1 Eagle DUB, 170mm length
Bottom Bracket
SRAM DUB, BB92 PressFit
Chain
SRAM XX1 Eagle, 12-speed, Gold finish
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Crankbrothers Synthesis E Carbon Trail wheelset, 110x15mm Boost front, 148x12mm Boost rear with XD driver
Rear Hub
Crankbrothers Synthesis E Carbon Trail wheelset, 110x15mm Boost front, 148x12mm Boost rear with XD driver
Rims
Crankbrothers Synthesis E Carbon Trail wheelset
Spokes
Crankbrothers Synthesis E Carbon Trail wheelset
Tires
Panaracer Aliso, TR, 3Comp, 29" x 2.4"
Brakes
Brakes
Magura MT Trail Carbon, Magura Storm HC rotors (203mm front, 180mm rear)
Brake Levers
Magura MT Trail Carbon
Cockpit
Stem
Production Privee R2R, 50mm length
Handlebar
Production Privee LGB, 780mm width
Grips
Production Privee CR35
Headset
IS42 upper, IS52 lower
Seat
Saddle
fi'zi:k Monte Enduro, Kium rails
Seatpost
BikeYoke Revive dropper, 160mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.421 mm | 1.342 mm | 1.296 mm | 1.262 mm |
| Bottom Bracket Height | 338 mm | 338 mm | 338 mm | 338 mm |
| Front Center | 758 mm | 783 mm | 810 mm | 834 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 122 mm | 122 mm | 122 mm | 122 mm |
| Stack | 608 mm | 608 mm | 617 mm | 626 mm |
| Reach | 428 mm | 453 mm | 476 mm | 496 mm |
| Top Tube Length | 580 mm | 605 mm | 630 mm | 650 |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 400 mm | 430 mm | 450 mm | 485 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 105 mm | 105 mm | 110 mm | 125 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1193 mm | 1218 mm | 1245 mm | 1269 mm |
| Bottom Bracket Drop | 36 mm | 36 mm | 36 mm | 36 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Shan N.5 037 Limited Edition belongs to the Productionprivee Shan model. 53 bikes variations carry this model name so far. You can get a glimpse at all models from 2020, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork
This bike has the Cane Creek HELM fork installed. The fork’s travel is 150mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The shock that’s installed on this bike is Cane Creek DB Air, with a travel distance of 140mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
When it comes to wheels, the Shan N.5 037 Limited Edition bike is equipped with the 29″ carbon model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Production Privee Shan N.5 037 Limited Edition has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Production Privee Shan N.5 037 Limited Edition includes a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
