Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 150mm -
Travel Rear 140mm -
Fork RockShox Lyrik Ultimate
-
Groupset XX1 Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Chromoly
Suspension Fork
RockShox Lyrik Ultimate, Charger 2.1 RC2 damper, DebonAir spring, high/low-speed compression adjust, rebound adjust, Maxle Stealth axle, 51mm offset
Rear Shock
RockShox Super Deluxe Ultimate, DebonAir spring, 2-position lever (Open/Firm), compression adjust, rebound adjust, 210mm x 55mm
Drivetrain
Rear Derailleur
SRAM XX1 Eagle, 12-speed, X-ACTUATION, long cage
Front Derailleur
None
Shift Levers
SRAM XX1 Eagle, 12-speed, X-ACTUATION
Cassette
SRAM XX1 Eagle XG-1299, 12-speed, 10-52 tooth, gold finish
Crank
SRAM XX1 Eagle DUB, Length: 170mm (SM/MD), 175mm (LG/XL)
Bottom Bracket
SRAM DUB
Chain
SRAM XX1 Eagle, 12-speed, with PowerLock, gold finish
Chain Guide
None
Pedals
None
Wheels
Front Hub
Crankbrothers Synthesis Carbon E7 wheelset, 110x15mm Boost front, 148x12mm Boost rear with XD driver
Rear Hub
Crankbrothers Synthesis Carbon E7 wheelset, 110x15mm Boost front, 148x12mm Boost rear with XD driver
Rims
Crankbrothers Synthesis Carbon E7 wheelset, Inner width: 31.5mm (front), 29.5mm (rear)
Spokes
Front: Sapim E-Light, Rear: Sapim Strong
Tires
Front: Panaracer Romero, High Output, Triple Compound, puncture-resistant wall, tubeless ready, 29" x 2.4", Rear: Panaracer Aliso, High Output, Triple Compound, puncture-resistant wall, tubeless ready, 29" x 2.4"
Brakes
Brakes
Formula Cura 4 Carbon, 4-piston, 6-bolt rotors (203mm front, 180mm rear)
Brake Levers
Formula Cura 4 Carbon, MixMaster clamps
Cockpit
Stem
Production Privee R2R, 7075 heavy-duty aluminum, 50mm length, 31.8mm bar clamp
Handlebar
Production Privee LGB, 7075-T6 double-butted aluminum, 780mm width, 25.4mm rise, 5° upsweep, 8° backsweep, 31.8mm clamp diameter
Grips
Production Privee CR35, 2-position adjustable, Forestal edition
Headset
Production Privee, IS42 upper, IS52 lower
Seat
Saddle
fi'zi:k Alpaca Terra X5, fiber-reinforced nylon shell, S-alloy rails, 249mm length, 145mm width
Seatpost
Crankbrothers Highline 7 dropper, 7076-T6 aluminum, BikeYoke Triggy X remote lever, Drop: 125mm (SM), 150mm (MD/LG), 170mm (XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.421 mm | 1.342 mm | 1.296 mm | 1.262 mm |
| Bottom Bracket Height | 338 mm | 338 mm | 338 mm | 338 mm |
| Front Center | 758 mm | 783 mm | 810 mm | 834 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 122 mm | 122 mm | 122 mm | 122 mm |
| Stack | 608 mm | 608 mm | 617 mm | 626 mm |
| Reach | 428 mm | 453 mm | 476 mm | 496 mm |
| Top Tube Length | 580 mm | 605 mm | 630 mm | 650 |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 400 mm | 430 mm | 450 mm | 485 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 105 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1193 mm | 1218 mm | 1245 mm | 1269 mm |
| Bottom Bracket Drop | 36 mm | 36 mm | 36 mm | 36 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Shan N.5 Explorer completes the Productionprivee Shan model. 53 bikes variations carry this model name so far. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
Production Privée Shan 27″ Classic 2021 is the most economical model, with a starting price of 3625$. Production Privée Shan Nº5 Petit Tonnerre 2021 on the other hand costs 8454$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Shan N.5 Explorer components
Fork
This bike has the RockShox Lyrik Ultimate fork installed. The fork’s travel is 150mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The shock that’s installed on this bike is RockShox Super Deluxe Ultimate, with a travel distance of 140mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
The Shan N.5 Explorer 2021 bike is equipped with 29″ carbon wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Shan N.5 Explorer comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Production Privee Shan N.5 Explorer bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
