Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 150mm -
Travel Rear 140mm -
Fork Cane Creek HELM
-
Groupset XX1 Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Chromoly
Suspension Fork
Cane Creek Helm MKII Air, Double-Air spring system (high-volume positive and negative air springs), high/low-speed compression adjust, low-speed rebound adjust, 44mm offset
Rear Shock
Cane Creek DB Kitsuma Air, high/low-speed compression adjust, high/low-speed rebound adjust, 210mm x 55mm
Drivetrain
Rear Derailleur
SRAM XX1 Eagle, 12-speed, X-ACTUATION, long cage
Front Derailleur
None
Shift Levers
SRAM XX1 Eagle, 12-speed, X-ACTUATION
Cassette
SRAM XX1 Eagle XG-1299, 12-speed, 10-52 tooth, gold finish
Crank
SRAM XX1 Eagle DUB, Length: 170mm (SM/MD), 175mm (LG/XL)
Bottom Bracket
SRAM DUB
Chain
SRAM XX1 Eagle, 12-speed, with PowerLock, gold finish
Chain Guide
None
Pedals
None
Wheels
Front Hub
Crankbrothers Synthesis Carbon E7 wheelset, 110x15mm Boost front, 148x12mm Boost rear with XD driver
Rear Hub
Crankbrothers Synthesis Carbon E7 wheelset, 110x15mm Boost front, 148x12mm Boost rear with XD driver
Rims
Crankbrothers Synthesis Carbon E7 wheelset, Inner width: 31.5mm (front), 29.5mm (rear)
Spokes
Front: Sapim E-Light, Rear: Sapim Strong
Tires
Front: Panaracer Romero, High Output, Triple Compound, puncture-resistant wall, tubeless ready, 29" x 2.4", Rear: Panaracer Aliso, High Output, Triple Compound, puncture-resistant wall, tubeless ready, 29" x 2.4"
Brakes
Brakes
Magura MT Trail Carbon, 4-piston, Magura Storm HC 6-bolt rotors (203mm front, 180mm rear)
Brake Levers
Magura MT Trail Carbon HC, ShiftMix 3 clamps
Cockpit
Stem
Production Privee R2R, 7075 heavy-duty aluminum, 50mm length, 31.8mm bar clamp
Handlebar
Production Privee LGB, 7075-T6 double-butted aluminum, 780mm width, 25.4mm rise, 5° upsweep, 8° backsweep, 31.8mm clamp diameter
Grips
Production Privee CR35, 2-position adjustable, Forestal edition
Headset
Production Privee, IS42 upper, IS52 lower
Seat
Saddle
fi'zi:k Alpaca Terra X5, fiber-reinforced nylon shell, S-alloy rails, 249mm length, 145mm width
Seatpost
Crankbrothers Highline 7 dropper, 7076-T6 aluminum, BikeYoke Triggy X remote lever, Drop: 125mm (SM), 150mm (MD/LG), 170mm (XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.421 mm | 1.342 mm | 1.296 mm | 1.262 mm |
| Bottom Bracket Height | 338 mm | 338 mm | 338 mm | 338 mm |
| Front Center | 758 mm | 783 mm | 810 mm | 834 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 122 mm | 122 mm | 122 mm | 122 mm |
| Stack | 608 mm | 608 mm | 617 mm | 626 mm |
| Reach | 428 mm | 453 mm | 476 mm | 496 mm |
| Top Tube Length | 580 mm | 605 mm | 630 mm | 650 |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 400 mm | 430 mm | 450 mm | 485 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 105 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1193 mm | 1218 mm | 1245 mm | 1269 mm |
| Bottom Bracket Drop | 36 mm | 36 mm | 36 mm | 36 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Shan N.5 Petit Tonnerre completes the Productionprivee Shan model. Production Privee released 53 bikes variations of this model so far. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
Production Privée Shan 27″ Classic 2021 is the cheapest bike model and costs 3625$. Production Privée Shan Nº5 Petit Tonnerre 2021 is the most expensive one and costs 8454$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork
This bike has the Cane Creek HELM fork installed. The fork’s travel is 150mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The Shan N.5 Petit Tonnerre has a rear shock with a travel of 140mm. The model Cane Creek DB Kitsuma Air is the one installed in this bike. Rear shocks improve riding comfort and give you greater control over all terrains. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
When it comes to wheels, the Shan N.5 Petit Tonnerre bike is equipped with the 29″ carbon model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Production Privee Shan N.5 Petit Tonnerre bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Production Privee Shan N.5 Petit Tonnerre comes with a dropper post. Therefore, climbing or descending will be a breeze.
