Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 200mm -
Travel Rear 215mm -
Fork Fox Factory Float 40
-
Groupset X01 -
Suspension Full -
Drivetrain 1 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Robust Blend Carbon frame
Suspension Fork
Fox 40 Factory Kashima, 203 mm
Rear Shock
Fox DHX2 Factory
Drivetrain
Rear Derailleur
SRAM X01 DH
Cassette
SRAM XG-795
Crank
SRAM X01 DH Carbon 165 mm 36t
Wheels
Rims
Newmen Evolution E.G.30 DH
Tires
Schwalbe Magic Mary / Big Betty Super DH
Brakes
Brakes
Magura MT7 Performance, 220 / 203 mm
Cockpit
Stem
SIXPACK Millenium DRM 35
Handlebar
SIXPACK Millenium 805
Seat
Saddle
SIXPACK Kamikaze
Seatpost
SIXPACK Seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.372 mm | 1.289 mm |
| Bottom Bracket Height | 353 mm | 353 mm | 353 mm |
| Front Center | 444 mm | 444 mm | 444 mm |
| Rake | 46 mm | 46 mm | 46 mm |
| Trail | 1384 mm | 1413 mm | 1443 mm |
| Stack | 629 mm | 638 mm | 638 mm |
| Reach | 440 mm | 465 mm | 495 mm |
| Top Tube Length | 562 mm | 589 mm | 619 mm |
| Seat Tube Angle | 79 ° | 79 ° | 79 ° |
| Head Tube Angle | 63 ° | 63 ° | 63 ° |
| Head Tube Length | 100 mm | 110 mm | 110 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm |
| Bottom Bracket Drop | 21 mm | 21 mm | 21 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
Rage CF 29 Highend completes the Propain Rage model. 44 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Propain Rage 3 CF 29 Start 2023 is the most affordable bike of this model and has a price of 4246$. On the other hand, Propain Rage 3 CF Mix Highend 2023, is the most expensive and costs 6709$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Downhill bikes average price
According to our math, the average price for a trustworthy Downhill bike is 3391$. However, this doesn’t mean that if you spend less money on a Downhill bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Downhill bikes average weight
Downhill bikes have an average weight of 15.89 kg (35.03 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Rage CF 29 Highend weighs 16.9 kg (37.26 lbs) and is a bit heavier than the average. To sum up, it’s 6.36% heavier than the average weight of Downhill bikes.
Overview of components
Fork
The Fox Factory Float 40 is included from the factory. It has a travel distance of 200mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
As for the rear shock, this bike has the Fox DHX2 Factory model, with a travel of 215mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When leaving the production line, the Rage CF 29 Highend model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Propain Rage CF 29 Highend is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
