Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 145mm -
Fork Fox Factory Float 34
-
Groupset X01 Eagle, Truvativ Descendant Carbon -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX Float 34 Factory Kashima
Rear Shock
FOX Float Factory DPS, 210mm x 50mm
Drivetrain
Rear Derailleur
SRAM X01 Eagle, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM X01 Eagle, 12-speed
Cassette
SRAM XG1295, 10-50 tooth, 12-speed
Crank
Truvativ Descendant Carbon
Bottom Bracket
BSA 73mm
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Newmen Evolution SL A 30
Rear Hub
Newmen Evolution SL A 30
Rims
Newmen Evolution SL A 30
Tires
Schwalbe Hans Dampf, Addix Soft, 27.5" x 2.35"
Brakes
Brakes
Magura MT Trail, 203mm front rotor, 180mm rear rotor
Brake Levers
Magura MT Trail
Cockpit
Stem
Newmen Evolution SL, 50mm length, 31.8mm clamp
Handlebar
Newmen Advanced Carbon, 760mm width, 31.8mm clamp
Headset
Tapered, IS42 top, IS52 bottom
Seat
Saddle
Selle Italia XR
Seatpost
Bikeyoke Revive dropper
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.43 mm | 1.39 mm | 1.33 mm | 1.29 mm |
| Bottom Bracket Height | 349 mm | 349 mm | 349 mm | 349 mm | 349 mm |
| Front Center | 693 mm | 717 mm | 737 mm | 757 mm | 781 mm |
| Rake | 39 mm | 40 mm | 39 mm | 39 mm | 39 mm |
| Trail | 116 mm | 114 mm | 116 mm | 116 mm | 116 mm |
| Stack | 583 mm | 583 mm | 592 mm | 592 mm | 601 mm |
| Reach | 386 mm | 409 mm | 426 mm | 446 mm | 466 mm |
| Top Tube Length | 535 mm | 560 mm | 580 mm | 600 mm | 624 mm |
| Seat Tube Angle | 75.7 ° | 75.7 ° | 75.7 ° | 75.7 ° | 75.7 ° |
| Seat Tube Length | 395 mm | 420 mm | 445 mm | 470 mm | 495 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 120 mm | 130 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1133 mm | 1157 mm | 1177 mm | 1197 mm | 1221 mm |
| Bottom Bracket Drop | 6 mm | 6 mm | 6 mm | 6 mm | 6 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Tyee AM Race is a Propain Tyee model. Propain released 82 bikes variations of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Trail bikes
Trail bikes weigh an average of 12.98 kg (28.62 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
slightly heavier than average, Tyee AM Race has a weight of 13.2 kg (29.1 lbs). To sum up, it’s 1.69% heavier than the average weight of Trail bikes.
Overview of components
Fork
This bike has the Fox Factory Float 34 fork installed. The fork’s travel is 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
Propain Tyee AM Race bike has the FOX Float Factory DPS model installed, and has a travel of 145mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
The Tyee AM Race 2018 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Tyee AM Race comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Propain Tyee AM Race bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
The Propain model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
