Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 140mm -
Travel Rear 130mm -
Fork RockShox Pike RCT3
-
Groupset X01, X01 Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
RockShox Pike RCT3 Solo Air
Rear Shock
RockShox Monarch RT3
Drivetrain
Rear Derailleur
SRAM Eagle X01, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM Eagle X01, 12-speed
Cassette
SRAM XG-1295, 10-50 tooth
Crank
SRAM X01 Eagle
Bottom Bracket
SRAM GXP BB92, pressfit
Chain
SRAM X01 Eagle, 12-speed
Pedals
N/A
Wheels
Front Hub
Deed hubs
Rear Hub
Deed hubs
Rims
Race Face AR 27, 27mm inner width
Tires
Maxxis Ardent Race
Brakes
Brakes
SRAM Level TLR, 180mm rotors
Brake Levers
SRAM Level TLR
Cockpit
Stem
Race Face Turbine, 50mm length
Handlebar
Race Face Next Carbon, 760mm width
Grips
Race Face Half Nelson
Headset
Cane Creek 40 Series, zero-stack, ZS44 top, ZS56 bottom
Seat
Saddle
Kore Fazer SL
Seatpost
Race Face Turbine, 125mm travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.39 mm | 1.35 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm |
| Stack | 624 mm | 633 mm | 644 mm |
| Reach | 436 mm | 456 mm | 476 mm |
| Top Tube Length | 606 mm | 623 mm | 651 mm |
| Seat Tube Angle | 74.2 ° | 74.2 ° | 74.2 ° |
| Seat Tube Length | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 444 mm | 444 mm | 444 mm |
| Wheelbase | 1171 mm | 1194 mm | 1207 mm |
| Bottom Bracket Drop | 32 mm | 32 mm | 32 mm |
| Standover Height | 116 mm | 126 mm | 136 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
Stage Max X01 Eagle is a Pyga Stage model. 8 bikes variations carry this model name so far. You can easily view all of the Pyga Stage bikes models from 2018, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
The fork installed on this bike is the RockShox Pike RCT3 model. The travel on this model is 140mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
As for the rear shock, this bike has the RockShox Monarch RT3 model, with a travel of 130mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When it comes to wheels, the Stage Max X01 Eagle bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Stage Max X01 Eagle comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This bike is available in 3 sizes. They vary from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
A dropper post is included with the Stage Max X01 Eagle. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
