Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 170mm -
Travel Rear 160mm -
Fork Fox Factory Float 36
-
Groupset X01 Eagle, X1 -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX 36 Float Factory, FIT GRIP2, Kashima coating, Boost
Rear Shock
FOX Float X2 Factory, 2-positions, EVOL, Kashima coating, Trunnion mount, 205x65mm
Drivetrain
Rear Derailleur
SRAM X01 Eagle
Front Derailleur
None
Shift Levers
SRAM X01 Eagle, 12-speed, Matchmaker X
Cassette
SRAM GX Eagle, XG-1275, 10-50 tooth
Crank
SRAM X1 Eagle Carbon, Boost, DUB, 170mm
Bottom Bracket
SRAM pressfit DUB MTB, 92mm
Chain
SRAM GX Eagle
Chain Guide
MRP 1X
Pedals
None
Wheels
Front Hub
Newmen Evolution SL A30 wheelset
Rear Hub
Newmen Evolution SL A30 wheelset
Rims
Newmen Evolution SL A30 wheelset, 30mm inner width
Spokes
Newmen Evolution SL A30 wheelset
Tires
Front: Schwalbe Magic Mary, Addix-Soft, TLE, SuperG, Kevlar, 27.5"x2.35", Rear: Schwalbe Rock Razor, Addix-Speedgrip, TLE, SuperG, Kevlar, 27.5"x2.35"
Brakes
Brakes
Front: SRAM Code RSC, SRAM Centerline 200mm 6-bolt rotor, Rear: SRAM Code RSC, SRAM Centerline 180mm 6-bolt rotor
Brake Levers
SRAM Code RSC
Cockpit
Stem
Race Face Turbine R 35, 40mm on 16"/18"/20", 50mm on 22"
Handlebar
Race Face NEXT R, 35mm diameter, 780mm, 35mm rise
Grips
SDG Slater
Headset
Acros AzX ZS44/ZS56
Seat
Saddle
SDG FLY MTN 2, Ti
Seatpost
FOX Transfer Factory, Kashima coating, 125mm on 16", 150mm on 18"/20"/22"
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.34 mm | 1.3 mm | 1.29 mm |
| Bottom Bracket Height | 365 mm | 365 mm | 365 mm | 365 mm |
| Front Center | 742 mm | 765 mm | 787 mm | 810 mm |
| Rake | 28 mm | 27 mm | 27 mm | 28 mm |
| Trail | 137 mm | 138 mm | 138 mm | 137 mm |
| Stack | 582 mm | 592 mm | 601 mm | 614 mm |
| Reach | 424 mm | 443 mm | 461 mm | 477 mm |
| Top Tube Length | 571 mm | 593 mm | 615 mm | 637 mm |
| Seat Tube Angle | 74.1 ° | 74.1 ° | 74.1 ° | 74.1 ° |
| Seat Tube Length | 395 mm | 425 mm | 455 mm | 490 mm |
| Head Tube Angle | 64.7 ° | 64.7 ° | 64.7 ° | 64.7 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 135 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1165 mm | 1188 mm | 1210 mm | 1233 mm |
| Bottom Bracket Drop | -10 mm | -10 mm | -10 mm | -10 mm |
| Standover Height | 722 mm | 740 mm | 755 mm | 776 mm |
| Wheels | 27" | 27" | 27" | 27" |
Model Overview
Jab 10.0 HD completes the Radon Jab model. There are 21 bikes that carry this model name. Check out the entire range from 2019 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Enduro bikes average price
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Enduro bikes
If we make a quick analysis of the average weight of an Enduro bike, we get 14.27 kg (31.46 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 13.8 kg (30.42 lbs), Radon bike is slightly lighter than average. To sum up, it’s 3.41% lighter than the average weight of Enduro bikes.
Jab 10.0 HD components
Fork
This bike has the Fox Factory Float 36 fork installed. The fork’s travel is 170mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The Jab 10.0 HD has a rear shock with a travel of 160mm. The model FOX Float X2 Factory is the one installed in this bike. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
As for the wheels, Radon Jab 10.0 HD 2019, has a 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Jab 10.0 HD comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Dropper post
Radon Jab 10.0 HD includes a dropper post. Therefore, climbing or descending will be a breeze.
