Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 160mm -
Fork RockShox Lyrik
-
Groupset X01 Eagle, Truvativ Descendant Carbon -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
RockShox Lyrik RCT3, 110x15mm Boost axle
Rear Shock
RockShox Super Deluxe RC3, DebonAir, trunnion mount, 205mm x 65mm
Drivetrain
Rear Derailleur
SRAM X01 Eagle, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM X01 Eagle, 12-speed, Matchmaker X
Cassette
SRAM XG-1275, 12-speed, 10-50 tooth
Crank
SRAM Descendant Eagle Carbon, 170mm length
Bottom Bracket
SRAM GXP, PressFit 92
Chain
SRAM PC-X01
Chain Guide
e*thirteen TRS Race SL
Pedals
N/A
Wheels
Front Hub
e*thirteen TRS, 110x15mm Boost front, 148x12mm Boost rear
Rear Hub
e*thirteen TRS, 110x15mm Boost front, 148x12mm Boost rear
Rims
e*thirteen TRS
Spokes
e*thirteen TRS
Tires
Front: Schwalbe Magic Mary, Addix-Soft, TLE, Kevlar, 27.5" x 2.35", Rear: Schwalbe Hans Dampf, Addix-Soft, TLE, Snake Skin, 27.5" x 2.35"
Brakes
Brakes
SRAM Code R, SRAM Elixir Centerline 6-bolt rotors, 200mm front, 180mm rear
Brake Levers
SRAM Code R
Cockpit
Stem
Race Face Turbine Basic R, 35mm clamp, 40mm length
Handlebar
Race Face Turbine R, 35mm clamp, 780mm width, 20mm rise
Grips
SDG Slater
Headset
Acros AZX, ZS44/ZS56
Seat
Saddle
SDG Fly Mtn 2, CrMo rails
Seatpost
SDG dropper, 120mm travel (16"), 150mm travel (18", 20")
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" |
|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.34 mm | 1.3 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm |
| Front Center | 742 mm | 765 mm | 787 mm |
| Rake | 44 mm | 43 mm | 43 mm |
| Trail | 116 mm | 117 mm | 117 mm |
| Stack | 582 mm | 592 mm | 601 mm |
| Reach | 424 mm | 443 mm | 461 mm |
| Top Tube Length | 571 mm | 593 mm | 615 mm |
| Seat Tube Angle | 74.6 ° | 74.6 ° | 74.6 ° |
| Seat Tube Length | 395 mm | 425 mm | 455 mm |
| Head Tube Angle | 65.2 ° | 65.2 ° | 65.2 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1165 mm | 1188 mm | 1210 mm |
| Bottom Bracket Drop | 14 mm | 14 mm | 14 mm |
| Standover Height | 722 mm | 739 mm | 755 mm |
| Wheels | 27" | 27" | 27" |
About this model
Jab 9.0 HD is part of the Radon Jab model. 21 bikes variations carry this model name so far. You can get a glimpse at all models from 2018, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Enduro bikes
If you want an acceptable Enduro bike you should know that the average price is 3599$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Enduro bikes average weight
Enduro bikes weigh an average of 14.27 kg (31.46 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
a bit lighter than average, Jab 9.0 HD has a weight of 13.3 kg (29.32 lbs). In other words, this model is 7.29% lighter than the average Enduro bike.
Jab 9.0 HD components
Fork
Radon Jab 9.0 HD 2018 bike is equipped with the RockShox Lyrik fork, and has 160mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this bike has the RockShox Super Deluxe RC3 model, with a travel of 160mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
When it comes to wheels, the Jab 9.0 HD bike is equipped with the 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Radon Jab 9.0 HD is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Dropper post
Radon Jab 9.0 HD includes a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
