Radon RENDER 8.0 2020
2020 E-bike
Estimate price |
4,587$
Weight | 23.5 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 140mm -
Fork RockShox Lyrik Select
-
Groupset SX Eagle, NX Eagle -
Suspension Full -
Motor Bosch 250W 75Nm mid-drive -
Battery Bosch Powertube 625Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
RENDER HYBRID; Material: Carbon main frame / Aluminium rear triangle, Max. width tire: 2.6", Powertube Capacity: 625 Wh
Suspension Fork
Rock Shox Lyrik Select E-Bike, Boost
Rear Shock
RockShox Deluxe Select+, 205mm x 55mm
Drivetrain
Rear Derailleur
SRAM SX Eagle, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM NX Eagle, Shiftmix, Single Click
Cassette
SRAM PG-1210, 11-50
Crank
Acid E-Crank, SRAM Eagle Chainring, 34T, 165mm
Chain
SRAM SX Eagle
Chain Guide
e*thirteen e*spec Plus
Pedals
not included
Wheels
Front Hub
Shimano Alivio HB-MT400-B, 110mm
Rear Hub
Shimano Alivio FH-MT400-B, 148mm
Rims
Alex MD 30
Spokes
DT Swiss Factory
Tires
Maxxis Minion DHF Skinwall Dual, EXO, TR, 29" x 2.5" WT
Brakes
Brakes
Magura MT Trail Custom
Brake Levers
Magura MT Trail Custom
Cockpit
Stem
Race Face Chester, 35mm; M/40mm, L/40mm, XL/60mm
Handlebar
Race Face Chester, 35 x 780mm, 20mm rise
Grips
SDG Slater
Headset
Acros Block-Lock, ZS56/ZS56
Seat
Saddle
Selle Italia X1
Seatpost
Radon Dropper, 31.6 x 130mm
Motor & Battery
Motor
Bosch Performance Line CX
Battery
Bosch Powertube 625Wh
Remote
Bosch Purion
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.36 mm | 1.34 mm |
| Bottom Bracket Height | 346 mm | 346 mm | 346 mm |
| Front Center | 759 mm | 783 mm | 806 mm |
| Rake | 45 mm | 45 mm | 45 mm |
| Trail | 121 mm | 121 mm | 121 mm |
| Stack | 607.7 mm | 616.8 mm | 630.5 mm |
| Reach | 432.1 mm | 451.9 mm | 469.1 mm |
| Top Tube Length | 583 mm | 606 mm | 628 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 75.5 ° |
| Seat Tube Length | 425 mm | 455 mm | 490 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 110 mm | 120 mm | 135 mm |
| Chainstay Length | 449 mm | 449 mm | 449 mm |
| Wheelbase | 1206 mm | 1230 mm | 1254 mm |
| Bottom Bracket Drop | 28 mm | 28 mm | 28 mm |
| Standover Height | 766 mm | 766 mm | 766 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
RENDER 8.0 is a Radon E Render model. Radon launched 21 e-bikes of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
Radon RENDER 8.0 2020 is the most affordable e-bike of this model and has a price of 4246$. On the other hand, Radon RENDER 10.0 HD SUPREME 2020, is the most expensive and costs 7219$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail e-bikes average price
Our math shows that the average cost of a dependable Trail e-bike is 3365$. However, even though the average price of a Trail e-bike is lower, you might still be able to get a top-quality e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4246$. Comparing the average cost of a Trail e-bike to this one, you will see that RENDER 8.0 price is 26.18% higher.
Trail e-bikes average weight
Trail e-bikes have an average weight of 23.7 kg (52.25 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Radon RENDER 8.0 it’s weighing 23.5 kg (51.81 lbs). At this weight, is slightly lighter than average. In other words, this model is 0.85% lighter than the average Trail e-bike.
RENDER 8.0 components
Fork
The RockShox Lyrik Select is included from the factory. It has a travel distance of 150mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Radon RENDER 8.0 e-bike has the RockShox Deluxe Select+ model installed, and has a travel of 140mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
When it comes to wheels, the RENDER 8.0 e-bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The RENDER 8.0 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Radon RENDER 8.0 e-bike has 3 sizes, in the range of 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
The Radon model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
