Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Fox Performance Elite Float 34
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX 34 Performance Elite, FIT4, 3 position adjustment, 15x110mm Boost
Rear Shock
FOX Float DPS Performance Elite, EVOL, 184x44mm
Drivetrain
Rear Derailleur
Shimano XT RD-M8000-SGS
Front Derailleur
Shimano XT FD-M8020-D, direct mount, sideswing
Shift Levers
Shimano XT SL-M8000-I, 11-speed, I-Spec
Cassette
Shimano XT CS-M8000, 11-42 tooth
Crank
Shimano XT FC-M8000, 175mm
Bottom Bracket
Shimano BB-MT500, pressfit
Chain
Shimano CN-HG601
Chain Guide
None
Pedals
None
Wheels
Front Hub
Newmen Evolution SL X.A25 wheelset
Rear Hub
Newmen Evolution SL X.A25 wheelset
Rims
Newmen Evolution SL X.A25 wheelset, 25mm inner width
Spokes
Newmen Evolution SL X.A25 wheelset
Tires
Front: Schwalbe Nobby Nic, Addix-Speedgrip, TLE, Kevlar, 29" x 2.35", Rear: Schwalbe Nobby Nic, Addix-Speedgrip, TLE, Kevlar, 29" x 2.25"
Brakes
Brakes
Front: Shimano XT BR-M8020, Shimano SLX SM-RT70 180mm rotor, Rear: Shimano BR-M8000, Shimano SLX SM-RT70 180mm rotor
Brake Levers
Front: Shimano BR-M8020, Rear: Shimano BR-M8000
Cockpit
Stem
Race Face Turbine Basic 35, 60mm on 16"/18"/20", 70mm on 22"
Handlebar
Race Face Turbine Basic, 35mm diameter, 760mm, 20mm rise
Grips
Ergon GE10, slim
Headset
FSA ZS44/IS52
Seat
Saddle
Selle Italia X1
Seatpost
FOX Transfer Performance, 125mm on 16"/18", 150mm on 20"/22"
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.4 mm | 1.36 mm | 1.33 mm |
| Bottom Bracket Height | 336 mm | 336 mm | 336 mm | 336 mm |
| Front Center | 709 mm | 725 mm | 747 mm | 770 mm |
| Rake | 53 mm | 52 mm | 53 mm | 53 mm |
| Trail | 94 mm | 95 mm | 94 mm | 94 mm |
| Stack | 613 mm | 613 mm | 622 mm | 631 mm |
| Reach | 422 mm | 439 mm | 457 mm | 476 mm |
| Top Tube Length | 581 mm | 597 mm | 619 mm | 641 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 420 mm | 450 mm | 480 mm | 510 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 105 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 451 mm | 451 mm | 451 mm | 451 mm |
| Wheelbase | 1157 mm | 1173 mm | 1195 mm | 1218 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 38 mm | 38 mm |
| Standover Height | 721 mm | 743 mm | 768 mm | 793 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
Skeen Trail 10.0 completes the Radon Skeen model. There are 20 bikes that carry this model name. Check out the entire range from 2019 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Trail bikes average weight
Trail bikes have an average weight of 12.98 kg (28.62 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Weighing 12.7 kg (28 lbs), the Skeen Trail 10.0 model is slightly lighter than average. In other words, this model is 2.2% lighter than the average Trail bike.
Overview of components
Fork
The Fox Performance Elite Float 34 is included from the factory. It has a travel distance of 130mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the FOX Float DPS Performance Elite rear shock model, which has a travel of 120mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
When leaving the production line, the Skeen Trail 10.0 model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Radon Skeen Trail 10.0 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Dropper post
Radon Skeen Trail 10.0 comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
