Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Fox Performance Float 34
-
Groupset GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX Performance 34 Float, FIT GRIP, 3 position adjustment, 15x110mm Boost
Rear Shock
FOX Float DPS Performance, LV, EVOL, 184x44mm
Drivetrain
Rear Derailleur
SRAM GX Eagle
Front Derailleur
None
Shift Levers
SRAM GX Eagle Trigger, 12-speed, Shiftmix
Cassette
SRAM GX Eagle, XG-1275, 10-50 tooth
Crank
SRAM GX Eagle, DUB, 175mm
Bottom Bracket
SRAM pressfit DUB, 92mm
Chain
SRAM GX
Chain Guide
None
Pedals
None
Wheels
Front Hub
Race Face AEffect SL24 wheelset
Rear Hub
Race Face AEffect SL24 wheelset
Rims
Race Face AEffect SL24 wheelset, 24mm inner width
Spokes
Race Face AEffect SL24 wheelset
Tires
Front: Schwalbe Nobby Nic, Addix-Speedgrip, TLE, Kevlar, 29" x 2.35", Rear: Schwalbe Nobby Nic, Addix-Speedgrip, TLE, Kevlar, 29" x 2.25"
Brakes
Brakes
Magura MT Trail Custom, Magura Storm HC 180mm rotors
Brake Levers
Magura MT Trail Custom
Cockpit
Stem
Race Face Turbine Basic 35, 60mm on 16"/18"/20", 70mm on 22"
Handlebar
Race Face Turbine Basic, 35mm diameter, 760mm, 20mm rise
Grips
Ergon GE10, slim
Headset
FSA ZS44/IS52
Seat
Saddle
Selle Italia X1
Seatpost
FOX Transfer Performance, 125mm on 16"/18", 150mm on 20"/22"
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.4 mm | 1.36 mm | 1.33 mm |
| Bottom Bracket Height | 336 mm | 336 mm | 336 mm | 336 mm |
| Front Center | 709 mm | 725 mm | 747 mm | 770 mm |
| Rake | 53 mm | 52 mm | 53 mm | 53 mm |
| Trail | 94 mm | 95 mm | 94 mm | 94 mm |
| Stack | 613 mm | 613 mm | 622 mm | 631 mm |
| Reach | 422 mm | 439 mm | 457 mm | 476 mm |
| Top Tube Length | 581 mm | 597 mm | 619 mm | 641 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 420 mm | 450 mm | 480 mm | 510 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 105 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 451 mm | 451 mm | 451 mm | 451 mm |
| Wheelbase | 1157 mm | 1173 mm | 1195 mm | 1218 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 38 mm | 38 mm |
| Standover Height | 721 mm | 743 mm | 768 mm | 793 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
Skeen Trail 9.0 is part of the Radon Skeen model. 20 bikes variations carry this model name so far. Check out the entire range from 2019 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Trail bikes
Trail bikes weigh an average of 12.98 kg (28.62 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Weighing 12.8 kg (28.22 lbs), the Skeen Trail 9.0 model is slightly lighter than average. In conclusion, the average Trail bike weighs 1.41% more than Skeen Trail 9.0.
Skeen Trail 9.0 components
Fork
The fork installed on this bike is the Fox Performance Float 34 model. The travel on this model is 130mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
Radon Skeen Trail 9.0 bike has the FOX Float DPS Performance model installed, and has a travel of 120mm. Rear shocks improve riding comfort and give you greater control over all terrains. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
When leaving the production line, the Skeen Trail 9.0 model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Dropper post
The Radon model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
