Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork RockShox Revelation RC
-
Groupset XT -
Suspension Full -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Revelation RC, 110x15mm Boost axle
Rear Shock
RockShox Monarch RT3, HVI, 184mm x 44mm
Drivetrain
Rear Derailleur
Shimano XT RD-M8000-SGS, 11-speed
Front Derailleur
Shimano XT FD-M8020-D, direct mount, sideswing
Shift Levers
Shimano XT SL-M8000-I, 11-speed, I-Spec
Cassette
Shimano SLX CS-M7000, 11-speed, 11-42 tooth
Crank
Shimano XT FC-M8000-I, 175mm length
Bottom Bracket
Shimano BB-MT500PA, PressFit
Chain
Shimano CN-HG601
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Mavic Crossmax, 110x15mm Boost front, 142x12mm rear
Rear Hub
Mavic Crossmax, 110x15mm Boost front, 142x12mm rear
Rims
Mavic Crossmax
Spokes
Mavic Crossmax
Tires
Schwalbe Nobby Nic, Addix-Speedgrip, TLE, Kevlar, 29" x 2.35" (front), 29" x 2.25" (rear)
Brakes
Brakes
Magura MT Trail Custom, 180mm Magura Storm HC 6-bolt rotors
Brake Levers
Magura MT Trail Custom
Cockpit
Stem
Race Face Turbine Basic, 31.8mm clamp, 60mm length (18"), 70mm length (20", 22")
Handlebar
Race Face Turbine, 31.8mm clamp, 760mm width, 0.5" rise
Grips
Ergon GE10 slim
Headset
FSA, ZS44/IS52
Seat
Saddle
Selle Italia X1
Seatpost
RockShox Reverb Stealth dropper, 125mm travel (18"), 150mm travel (20", 22")
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 18" | 20" | 22" |
|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.36 mm | 1.33 mm |
| Bottom Bracket Height | 336 mm | 336 mm | 336 mm |
| Front Center | 725 mm | 747 mm | 770 mm |
| Rake | 52 mm | 53 mm | 53 mm |
| Trail | 95 mm | 94 mm | 94 mm |
| Stack | 609 mm | 618 mm | 627 mm |
| Reach | 435 mm | 453 mm | 472 mm |
| Top Tube Length | 593 mm | 615 mm | 637 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1169 mm | 1191 mm | 1214 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 38 mm |
| Standover Height | 739 mm | 764 mm | 789 mm |
| Wheels | 29" | 29" | 29" |
About this model
Skeen Trail 9.0 29″ completes the Radon Skeen model. Radon released 20 bikes variations of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Trail bikes
The average weight for Trail bikes is 12.98 kg (28.62 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
With a weight of 13.2 kg (29.1 lbs), Radon bike is slightly heavier than average. In short, the average Trail bike weight is 1.69% lower than this one.
Overview of components
Fork
The Skeen Trail 9.0 29″ comes factory-installed with the RockShox Revelation RC fork. This has a travel range of 130mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Radon Skeen Trail 9.0 29″ bike has the RockShox Monarch RT3 model installed, and has a travel of 120mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The wheels on Skeen Trail 9.0 29″ are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Radon Skeen Trail 9.0 29″ has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Dropper post
Radon Skeen Trail 9.0 29″ includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
