Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 130mm -
Fork RockShox Pike RCT3
-
Groupset GX Eagle, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Pike RCT3, 110x15mm Boost axle
Rear Shock
RockShox Monarch RT3, 190mm x 51mm
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM GX Eagle, 12-speed, Shiftmix
Cassette
SRAM XG-1275, 12-speed, 10-50 tooth
Crank
SRAM Descendant 7k, 175mm length
Bottom Bracket
SRAM GXP, PressFit
Chain
SRAM GX Eagle, 12-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
SUNringlé Duroc, 110x15mm Boost front, 148x12mm Boost rear
Rear Hub
SUNringlé Duroc, 110x15mm Boost front, 148x12mm Boost rear
Rims
SUNringlé Duroc, 30mm
Spokes
SUNringlé Duroc
Tires
Schwalbe Nobby Nic, Addix-Speedgrip, TLE, Kevlar, 27.5" x 2.6"
Brakes
Brakes
Magura MT Trail Custom, 180mm Magura Storm 6-bolt rotors
Brake Levers
Magura MT Trail Custom
Cockpit
Stem
Race Face Aeffect, 35mm clamp, 50mm length (16", 18"), 60mm length (20", 22")
Handlebar
Race Face Aeffect, 35mm clamp, 760mm width, 20mm rise
Grips
Ergon GE10 slim
Headset
Acros AiX, IS41/IS52
Seat
Saddle
Selle Italia X1
Seatpost
JD Vario dropper, 120mm travel (16", 18"), 150mm travel (20", 22")
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.44 mm | 1.42 mm | 1.4 mm |
| Bottom Bracket Height | 329 mm | 329 mm | 329 mm | 329 mm |
| Front Center | 713 mm | 731 mm | 748 mm | 766 mm |
| Rake | 52 mm | 52 mm | 51 mm | 51 mm |
| Trail | 90 mm | 90 mm | 91 mm | 91 mm |
| Stack | 600 mm | 609 mm | 619 mm | 628 mm |
| Reach | 407 mm | 422 mm | 435 mm | 450 mm |
| Top Tube Length | 569 mm | 587 mm | 603 mm | 621 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 425 mm | 470 mm | 500 mm | 530 mm |
| Head Tube Angle | 67.6 ° | 67.6 ° | 67.6 ° | 67.6 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 135 mm |
| Chainstay Length | 429 mm | 429 mm | 429 mm | 429 mm |
| Wheelbase | 1141 mm | 1159 mm | 1176 mm | 1194 mm |
| Bottom Bracket Drop | 26 mm | 26 mm | 26 mm | 26 mm |
| Standover Height | 735 mm | 746 mm | 766 mm | 791 mm |
| Wheels | 27" | 27" | 27" | 27" |
About this model
Slide FE 9.0 completes the Radon Slide model. Radon released 20 bikes variations of this model so far. Take a sneak peek at all Radon Slide bikes models from 2018, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Trail bikes average weight
On a deeper look, we notice that the average weight of a Trail bike is 12.98 kg (28.62 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Radon Slide FE 9.0 it’s weighing 13.1 kg (28.88 lbs). At this weight, is slightly heavier than average. In other words, this model is 0.92% heavier than the average Trail bike.
Slide FE 9.0 components
Fork
The fork installed on this bike is the RockShox Pike RCT3 model. The travel on this model is 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The shock that’s installed on this bike is RockShox Monarch RT3, with a travel distance of 130mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
The wheels on Slide FE 9.0 are the 27.5″ aluminum type. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Radon Slide FE 9.0 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Dropper post
Radon Slide FE 9.0 comes with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
