Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 170mm -
Travel Rear 170mm -
Fork Fox Performance Elite Float 36
-
Groupset GX Eagle, Truvativ Stylo -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX 36 Float, Performance Elite, FIT GRIP2, Boost
Rear Shock
FOX Float DPX2 Performance Elite, EVOL, 216x63mm
Drivetrain
Rear Derailleur
SRAM GX Eagle
Front Derailleur
None
Shift Levers
SRAM GX Eagle, 12-speed, Matchmaker
Cassette
SRAM GX Eagle, XG-1275, 10-50 tooth
Crank
SRAM Stylo Eagle 7k, Boost, DUB, 170mm
Bottom Bracket
SRAM DUB, BSA 73
Chain
SRAM GX
Chain Guide
e*thirteen TRS+
Pedals
None
Wheels
Front Hub
DT Swiss E1700 Spline wheelset
Rear Hub
DT Swiss E1700 Spline wheelset
Rims
DT Swiss E1700 Spline wheelset, 30mm inner width
Spokes
DT Swiss E1700 Spline wheelset
Tires
Front: Schwalbe Magic Mary, Addix-Soft, TLE, Kevlar, 29"x2.35", Rear: Schwalbe Hans Dampf, Addix-Soft, TLE, Kevlar, 29"x2.35"
Brakes
Brakes
Front: SRAM Code R, SRAM Centerline 200mm 6-bolt rotor, Rear: SRAM Code R, SRAM Centerline 180mm 6-bolt rotor
Brake Levers
SRAM Code R
Cockpit
Stem
Race Face Turbine R 35, 40mm
Handlebar
Race Face Turbine, 35mm diameter, 800mm, 20mm rise
Grips
SDG Slater
Headset
FSA, ZS44/ZS56
Seat
Saddle
SDG FLY MTN 2, CrMo
Seatpost
FOX Transfer Performance, 150mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" | 21" |
|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.36 mm | 1.34 mm |
| Bottom Bracket Height | 348 mm | 348 mm | 348 mm |
| Front Center | 793 mm | 811 mm | 830 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 112 mm | 112 mm | 112 mm |
| Stack | 639 mm | 648 mm | 657 mm |
| Reach | 463 mm | 477 mm | 492 mm |
| Top Tube Length | 602 mm | 620 mm | 638 mm |
| Seat Tube Angle | 76.8 ° | 76.8 ° | 76.8 ° |
| Seat Tube Length | 435 mm | 455 mm | 475 mm |
| Head Tube Angle | 65.8 ° | 65.8 ° | 65.8 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1238 mm | 1256 mm | 1275 mm |
| Bottom Bracket Drop | 26 mm | 26 mm | 26 mm |
| Standover Height | 736 mm | 754 mm | 767 mm |
| Wheels | 29" | 29" | 29" |
About this model
Swoop 9.0 belongs to the Radon Swoop model. Radon released 26 bikes variations of this model so far. Check out the entire range from 2019 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Enduro bikes average price
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Enduro bikes
If we make a quick analysis of the average weight of an Enduro bike, we get 14.27 kg (31.46 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Swoop 9.0 weighs 14.2 kg (31.31 lbs) and is slightly lighter than the average. In other words, this model is 0.49% lighter than the average Enduro bike.
Overview of components
Fork
The fork installed on this bike is the Fox Performance Elite Float 36 model. The travel on this model is 170mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The Swoop 9.0 has a rear shock with a travel of 170mm. The model FOX Float DPX2 Performance Elite is the one installed in this bike. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
When leaving the production line, the Swoop 9.0 model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Swoop 9.0 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Dropper post
The Radon model is also equipped with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
