Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Fork Marzocchi Bomber Z2
-
Groupset Deore -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
Marzocchi Bomber Z2, RAIL damper, 51mm offset
Rear Shock
None
Drivetrain
Rear Derailleur
Shimano Deore M5100, 11-speed
Front Derailleur
None
Shift Levers
Shimano Deore M5100, 11-speed
Cassette
Shimano Deore M5100, 11-speed
Crank
Shimano Deore M5100, 170mm length
Bottom Bracket
73mm English threaded
Chain
Shimano Deore M5100, 11-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
110x15mm Boost front, 148x12mm Boost rear with HG driver
Rear Hub
110x15mm Boost front, 148x12mm Boost rear with HG driver
Rims
WTB STi30
Tires
Front: Maxxis Minion DHF, 3C, EXO+, TR, 29" x 2.5", Rear: Maxxis Minion DHR II, 3C, EXO+, TR, 29" x 2.4"
Brakes
Brakes
Shimano Deore M6100, 2-piston, 180mm rotors
Brake Levers
Shimano Deore M6100
Cockpit
Stem
Ragley Alloy, 50mm length
Handlebar
Ragley Alloy, Width: 780mm (MD), 800mm (LG/XL)
Grips
Ragley, lock-on
Headset
ZS44/28.6 upper, ZS56/40 lower
Seat
Saddle
Ragley Tracker
Seatpost
Brand-X Ascend dropper, Drop: 150mm (MD), 170mm (LG/XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.4 mm | 1.36 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm |
| Front Center | 770 mm | 790 mm | 813 mm |
| Rake | 56 mm | 52 mm | 52 mm |
| Trail | 113 mm | 117 mm | 117 mm |
| Stack | 637 mm | 646.1 mm | 655.2 mm |
| Reach | 443 mm | 463 mm | 483 mm |
| Top Tube Length | 628 mm | 648 mm | 670 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 420 mm | 460 mm | 500 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1200 mm | 1220 mm | 1244 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
Big Al 1.0 is a Ragley Big Al model. Ragley launched 3 bikes of this model so far. You can easily view all of the Ragley Big Al bikes models from 2021, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
The fork installed on this bike is the Marzocchi Bomber Z2 model. The travel on this model is 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
The wheels on Big Al 1.0 are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Big Al 1.0 comes in 3 sizes, that range from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Ragley Big Al 1.0 comes with a dropper post. Therefore, climbing or descending will be a breeze.
