Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 150mm -
Fork RockShox Revelation RC
-
Groupset NX Eagle, Truvativ Descendant -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Chromoly
Suspension Fork
Rockshox Revelation, 51mm offset
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM NX Eagle, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM NX Eagle, 12-speed
Cassette
SRAM NX Eagle, 12-speed, 11-50 tooth
Crank
Truvativ Descendant DUB, 170mm length
Bottom Bracket
SRAM DUB, 73mm BSA threaded
Chain
12-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
SUNringlé Duroc 35 Comp wheelset, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rear Hub
SUNringlé Duroc 35 Comp wheelset, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rims
SUNringlé Duroc 35 Comp wheelset, tubeless ready with rim tape installed and tubeless valves included
Spokes
SUNringlé Duroc 35 Comp wheelset
Tires
Front: Maxxis Minion DHF, 3C MaxxTerra, EXO+, TR, 29" x 2.5" WT, Rear: Maxxis Minion DHR II, 3C MaxxTerra, EXO+, TR, 29" x 2.4" WT
Brakes
Brakes
SRAM Guide T, 4-piston, 180mm rotors
Brake Levers
SRAM Guide T
Cockpit
Stem
Ragley Stubbing, 50mm length
Handlebar
Ragley Alloy, Black, 25mm rise, 780mm width
Grips
Ragley lock-on
Headset
FSA No.9, tapered, ZS44/28.6 upper, EX44/40 lower
Seat
Saddle
Ragley Tracker
Seatpost
Brand-X Ascend dropper, Drop: 150mm (MD/LG), 170mm (XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.4 mm | 1.36 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm |
| Front Center | 770 mm | 790 mm | 813 mm |
| Rake | 56 mm | 52 mm | 52 mm |
| Trail | 113 mm | 117 mm | 117 mm |
| Stack | 637 mm | 646.1 mm | 655.2 mm |
| Reach | 443 mm | 463 mm | 483 mm |
| Top Tube Length | 628 mm | 648 mm | 670 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 420 mm | 460 mm | 500 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1200 mm | 1220 mm | 1244 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
Big Wig completes the Ragley Big Wig model. Ragley released 4 bikes variations of this model so far. You can easily view all of the Ragley Big Wig bikes models from 2020, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Enduro bikes average price
According to our calculations, the average cost of an Enduro bike that is reliable is 3599$. However, this doesn’t mean that if you spend less money on an Enduro bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Big Wig components
Fork
Ragley Big Wig 2020 bike is equipped with the RockShox Revelation RC fork, and has 150mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The Big Wig 2020 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Ragley Big Wig is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Ragley Big Wig bike has 3 sizes, in the range of 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Ragley Big Wig comes with a dropper post. Therefore, climbing or descending will be a breeze.
