Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Fork RockShox Recon Silver RL
-
Groupset Deore, Suntour SR -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
Rockshox Recon RL, 46mm offset
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Deore M6000, 10-speed
Front Derailleur
N/A
Shift Levers
Shimano Deore M6000, 10-speed
Cassette
SunRace CSMS2, 10-speed, 11-46 tooth
Crank
SR Suntour Zeron, 170mm length
Bottom Bracket
SR Suntour Zeron, 73mm BSA threaded
Chain
10-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
WTB Serra wheelset, 32 hole, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rear Hub
WTB Serra wheelset, 32 hole, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rims
WTB Serra wheelset, 32 hole, tubeless ready with rim tape installed and tubeless valves included
Spokes
WTB Serra wheelset
Tires
Front: Maxxis Minion DHF, 3C MaxxTerra, EXO+, TR, 27.5" x 2.6", Rear: Maxxis Minion DHR II, 3C MaxxTerra, EXO+, TR, 27.5" x 2.6"
Brakes
Brakes
Shimano MT400, 180mm rotors
Brake Levers
Shimano MT400
Cockpit
Stem
Ragley, 50mm length, 3° rise
Handlebar
Ragley Alloy, Black, 25mm rise, 780mm width
Grips
Ragley lock-on
Headset
FSA Orbit 57E ZS, tapered, ZS44/28.6 upper, ZS56/40 lower
Seat
Saddle
Ragley Tracker
Seatpost
Ragley, 400mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.41 mm | 1.36 mm | 1.33 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 716 mm | 740 mm | 764 mm | 788 mm |
| Rake | 42 mm | 41 mm | 42 mm | 42 mm |
| Trail | 116 mm | 117 mm | 116 mm | 116 mm |
| Stack | 598.3 mm | 610 mm | 616.4 mm | 625.4 mm |
| Reach | 412 mm | 432 mm | 452 mm | 472 mm |
| Top Tube Length | 595.8 mm | 618.6 mm | 641.4 mm | 664.1 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 380 mm | 420 mm | 460 mm | 500 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1134 mm | 1158 mm | 1182 mm | 1206 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Marley 2.0 belongs to the Ragley Marley model. Ragley released 4 bikes variations of this model so far. Take a sneak peek at all Ragley Marley bikes models from 2020, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Marley 2.0 components
Fork
Ragley Marley 2.0 2020 bike is equipped with the RockShox Recon Silver RL fork, and has 130mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When it comes to wheels, the Marley 2.0 bike is equipped with the 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Ragley Marley 2.0 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
