Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Alloy Gravel, Thru-Axle, Disc Tabs, Taper Headtube
Suspension Fork
Alloy SPF Formed, Tapered Steerer, Thru-Axle, Disc Post Mount
Drivetrain
Rear Derailleur
Shimano Claris RD-2000, 8 Speed
Front Derailleur
Shimano Claris FD-2000
Shift Levers
Shimano Claris ST-2000, 8 Speed
Cassette
Shimano Claris HG-50 8 Speed, 11-32
Crank
Alloy 3peice Road Crank, 46/34 Tooth, Square Taper
Bottom Bracket
Sealed Cartirdge Bearing
Chain
KMC X8
Pedals
Resin Platform Pedal
Wheels
Front Hub
Alloy Disc, Thru-Axle 15mm, 28 Hole
Rear Hub
Alloy Disc, Thru-Axle, 28 Hole
Rims
Raleigh Alloy Double Wall, 700c, 28 Hole
Spokes
14g Stainless with Brass Nipples
Tires
Clement X'PLOR USH, 700x35c
Brakes
Brakes
Tektro Lyra Mechanical Disc, 160mm Rotors
Brake Levers
Shimano Claris
Cockpit
Stem
Raleigh 7° 3D Forged, 31.8, 90/100/110mm
Handlebar
Raleigh 200 series 31.8 with 12 Degree Flare, 38/40/42/44
Headset
Integrated Cartridge Bearings
Seat
Saddle
Raleigh Woman's Series Saddle with Steel Rail
Seatpost
Raleigh Alloy Micro Adjust 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.44 mm | 1.51 mm | 1.52 mm | 1.54 mm |
| Bottom Bracket Height | 276 mm | 276 mm | 276 mm | 279 mm | 279 mm |
| Front Center | 576 mm | 584 mm | 588 mm | 593 mm | 601 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 73 mm | 68 mm | 63 mm | 61 mm | 60 mm |
| Stack | 502 mm | 527 mm | 548 mm | 562 mm | 583 mm |
| Reach | 362 mm | 365 mm | 364 mm | 370 mm | 378 mm |
| Top Tube Length | 501 mm | 516 mm | 526 mm | 541 mm | 556 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 435 mm | 460 mm | 485 mm | 510 mm | 535 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 105 mm | 130 mm | 150 mm | 165 mm | 185 mm |
| Chainstay Length | 411 mm | 411 mm | 411 mm | 411 mm | 411 mm |
| Wheelbase | 976 mm | 984 mm | 988 mm | 994 mm | 1002 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 70 mm | 70 mm |
| Standover Height | 706 mm | 731 mm | 756 mm | 776 mm | 801 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Amelia 1 is part of the Raleigh Amelia model. Raleigh released 5 bikes variations of this model so far. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Raleigh Amelia 1 2019 is the cheapest bike model and costs 849$. Raleigh Amelia 2 2019 is the most expensive one and costs 999$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 849$. Comparing the average cost of a Gravel bike to this one, you will see that Amelia 1 price is 189.99% smaller.
Overview of components
Fork material
The fork on this bike is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels size
The Amelia 1 2019 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Raleigh Amelia 1 is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
